Panduit PH10-8R-E | Loose Piece Ring Terminal | UPC - 07498381810
Regular price
$44.38
Unit price
Description
Description
Panduit Pan-Term Terminal, Insulated Heat Shrink, Series: PH-R, 12 to 10 AWG Conductor, #8 Stud, 1.22 in Length, Brazed Seam/Standard Barrel, 1/4 in L Barrel, Ring Tongue, 0.37 in W Tongue, 600 VAC, Specifications: 5/16 in L Wire Strip, 1.22 in Clearance, -65 to 230 deg F, Copper, TiN Coated, Yellow
- Heat shrinkable polyolefin insulated with hot melt sealant
- Standard barrel configuration
- Heat shrink sleeving forms a protective barrier to provide environmentally sealed terminations ideal for high moisture applications
- Ring tongue design assures a secure connection in high vibration applications
- Brazed seam protects terminal barrel from splitting during the crimp process
- Heat shrink installation is completed with a standard heat gun
- 300 deg F shrink temperature
Panduit Panduit PH10-8R-E | Loose Piece Ring Terminal | UPC - 07498381810 Key Specs
| Stud Size | #8 |
| Insulation Material | Heat Shrink |
| Maximum Wire Size (AWG) | #10 |
| Minimum Wire Size (AWG) | #12 |
| Maximum Metric Conductor Size (mm²) | 6 |
| Minimum Metric Conductor Size (mm²) | 4 |
| Wire Strip Length (In.) | 5/16 |
| Wire Strip Length (mm) | 7.9 |
| Standards Met | UL 486A/B, and CSA 22.2 No.65 |
| Base Material | Copper |
| Maximum Voltage (V) | 600 |
| Maximum Voltage (kV) | 0.6 |
| Finish/Coating | Tin-Plated |
| Color Code | Yellow |
| Barrel Type | Standard |
| Flammability Rating | UL94-HB |
| Maximum Operating Temperature (°C) | 125 |
| Maximum Operating Temperature (°F) | 257 |
| Maximum Wire Insulation Diameter (In.) | 0.24 |
| Maximum Wire Insulation Diameter (mm) | 6.1 |
Panduit Panduit PH10-8R-E | Loose Piece Ring Terminal | UPC - 07498381810 Environmental Information
| Panduit's RoHS Statement | Download and View |
