Panduit PISR500-1 | Multi-Tap Connectors, In-Line Splicer/Reducer |...
Description
Description
Panduit Pan-Term splices are designed and manufactured for fast assembly, and long reliable performance. As the demand for splices increases, it becomes essential to provide a complete system for termination products. We provide an extensive line of tooling designed specifically to provide optimum performance when used as a system for terminating.
Panduit Pan-Term Splicer/Reducer, Dual Rated Inline Multi-Tap, Series: PISR, Stranded Copper/Aluminum Conductor, 6 AWG to 500 kcmil Conductor, Screw, 600 VAC, 1.62 in L Wire Strip, 500 in-lb Tighting Torque, 3/8 in Hex Screw, 90 deg C, Aluminum Alloy, Tin Plated, 5.25 in L x 1.72 in W x 2.63 in H
Features + Benefits
- Each port pre-filled with oxide inhibiting joint compound seals out air and moisture to deter surface oxidation
- Made from high strength, extruded aluminum alloy to provide premium electrical and mechanical performance
- Insulated with clear PVC to eliminate the need for taping and allow for visual inspection of the complete conductor insertion
- Wide wire range taking capability minimizes inventory requirements
- Plated steel or aluminum set screw provides high strength, durable electrical contact between conductor and connector
- Flexible design can be used as a splice or reducer
- Dual rated for use with copper or aluminum conductors
Panduit Panduit PISR500-1 | Multi-Tap Connectors, In-Line Splicer/Reducer | UPC - 07498357574 Key Specs
| Product Type | Multi-Tap Connectors, In-Line Splicer/Reducer |
| Sub Brand | Pan-Lug |
| Insulation Material | Clear PVC |
| Standards Met | CSA CERTIFIED/UL LISTED |
| Overall Length (In.) | 5.25 |
| Overall Length (mm) | 133.4 |
| Overall Width (In.) | 1.72 |
| Overall Width (mm) | 43.7 |
| Overall Height (In.) | 2.6 |
| Overall Height (mm) | 66.8 |
| Wire Strip Length (In.) | 1.62 |
| Wire Strip Length (mm) | 41.1 |
| Part Features | Each port pre-filled with oxide inhibiting joint compound seals out air and moisture to deter surface oxidation |
Panduit Panduit PISR500-1 | Multi-Tap Connectors, In-Line Splicer/Reducer | UPC - 07498357574 Data Sheets
| Catalog Cut Sheets | Catalog Cut Sheet - PISR2-1 Product Page | Download and View |
| Part Drawings | Part Drawing - PDF - C41359_05PISR | Download and View |
| MSDS | Safety Data Sheet T-MSDS-005-PC | Download and View |
Panduit Panduit PISR500-1 | Multi-Tap Connectors, In-Line Splicer/Reducer | UPC - 07498357574 Environmental Information
| Panduit's RoHS Statement | Download and View |
