Panduit PLT1M-L8-7 | CTie,4"L,Mini,Nyl,SL/VLStripe,PK50
Regular price
$1.70
Unit price
Description
Description
Panduit PLT1M-L8-7 | CTie,4"L,Mini,Nyl,SL/VLStripe,PK50
Pan-Ty locking tie, miniature cross section, 4.0" (102mm) length, nylon 6.6, slate/violet stripe.
Panduit PLT1M-L8-7 - CABLE TIE - 3.9" CABLE TIE 18LB .87"
Specifications
Specifications
Panduit - PLT1M-L8-7 - Product Categories
- Wire Routing, Management & Protection
- Cable Ties & Wire Ties
Panduit - PLT1M-L8-7 - Specifications
| Brand Name | Panduit |
|---|---|
| Manufacturer Part Number | PLT1M-L8-7 |
| Item Description | CTie,4"L,Mini,Nyl,SL/VLStripe,PK50 |
| Product Type | Cable Tie |
| Sub Brand | Pan-Ty |
| Color | Slate/Violet |
| Environment | Indoor |
| Material | Nylon 6.6 |
| Overall Length (In.) | 4 |
| Overall Length (mm) | 102 |
| Body Width (In.) | 0.1 |
| Body Width (mm) | 2.5 |
| Body Thickness (In.) | 0.036 |
| Body Thickness (mm) | 0.9 |
| Maximum Bundle Diameter (In.) | 0.87 |
| Maximum Bundle Diameter (mm) | 22.1 |
| Minimum Bundle Diameter (In.) | 0.06 |
| Minimum Bundle Diameter (mm) | 1.5 |
| Minimum Loop Tensile Strength (N) | 80 |
| Minimum Loop Tensile Strength (lb) | 18 |
| Maximum Operating Temperature (°C) | 85 |
| Maximum Operating Temperature (°F) | 185 |
| Minimum Operating Temperature (°C) | -60 |
| Minimum Operating Temperature (°F) | -76 |
| Minimum Installation Temperature (°C) | -20 |
| Minimum Installation Temperature (°F) | -4 |
| Standards Met | CSA Certified, UL Recognized (File #E56854), UL 62275 Compliant (Type 1, 11), RoHS Compliant |
| For Use With | GTS-E, GS2B-E, PTS |
| Part Features | One-piece, all nylon cable tie accommodate a maxinum bundle diamter of 0.82" (21mm). |
Panduit - PLT1M-L8-7 - Package Information
| UPC | 07498353984 |
|---|---|
| Standard Package Quantity | 50 |
| Standard Package Volume (cf) | 0.0043 |
| Standard Ctn. Quantity | 1000 |
| Standard Ctn. Volume (cf) | 0.0868 |
