Panduit PLT2.5S-M0 | Pan-Ty PLT2.5S-M0 Cable Tie, Black, UV PA6.6, ...
Description
Description
Panduit PLT2.5S-M0 Locking Cable Ties are designed to satisfy the needs of weather resistant applications, while delivering consistent performance and reliability. Featuring a curved tip to allow for easy pick up from flat surfaces and faster initial threading. Standard cross section, 9.8" (249mm) length. Made of Weather Resistant Nylon 6.6 with high resistance to ultraviolet light, are black in color and come in packages of 1000.
Panduit PLT2.5S-M0 Cable Tie, 9.8 L (249mm), Standard, Weather-resistant, Black, Pack Of 1000
Specifications
Specifications
Panduit - PLT2.5S-M0 - Product Categories
- Wire Routing, Management & Protection
- Cable Ties & Wire Ties
Panduit - PLT2.5S-M0 - Specifications
| Brand Name | Panduit |
|---|---|
| Manufacturer Part Number | PLT2.5S-M0 |
| Item Description | Pan-Ty PLT2.5S-M0 Cable Tie, Black, UV PA6.6, 9.8"L, 50lb, PK1000 |
| Product Type | Premium Cable Tie |
| Color | Black |
| Environment | Indoor/Outdoor |
| Material | Weather Resistant Nylon 6.6 |
| Resistance Properties | UV Resistant |
| Overall Length (In.) | 9.8 |
| Overall Length (mm) | 249 |
| Body Width (In.) | 0.19 |
| Body Width (mm) | 4.8 |
| Body Thickness (In.) | 0.052 |
| Body Thickness (mm) | 1.3 |
| Maximum Bundle Diameter (In.) | 2.5 |
| Maximum Bundle Diameter (mm) | 63.5 |
| Minimum Bundle Diameter (In.) | 0.06 |
| Minimum Bundle Diameter (mm) | 1.5 |
| Minimum Loop Tensile Strength (N) | 222 |
| Minimum Loop Tensile Strength (lb) | 50 |
| Maximum Operating Temperature (°C) | 85 |
| Maximum Operating Temperature (°F) | 185 |
| Minimum Operating Temperature (°C) | -60 |
| Minimum Operating Temperature (°F) | -76 |
| Minimum Installation Temperature (°C) | -20 |
| Minimum Installation Temperature (°F) | -4 |
| Standards Met | CSA Certified, UL Recognized (File #E56854), UL 62275 Compliant (Type 2S, 21S), RoHS Compliant |
| For Use With | GTS-E, GS2B-E, GTH-E, GS4H-E, PTS, PPTS, PTH, STS2, STH2 |
| Part Features | One-piece locking wedge for consistent performance and reliability. Low thread force and high loop tensile strength. |
| Cable Tie Diameter | 10" |
| Type | CABLES TIES AND ACCESSORIES |
| UNSPSC Code | 39121703 |
Panduit - PLT2.5S-M0 - Package Information
| UPC | 07498353602 |
|---|---|
| Standard Package Quantity | 1000 |
| Standard Package Volume (cf) | 0.3345 |
| Standard Ctn. Quantity | 10000 |
| Standard Ctn. Volume (cf) | 3.3446 |
