Panduit PLT2H-L0 | Pan-Ty PLT2H-L0 Cable Tie, Black, UV PA6.6, 8.1&...
Description
Description
Panduit PLT2H-L0 Locking Cable Ties are designed to satisfy the needs of weather resistant applications, while delivering consistent performance and reliability. Featuring a curved tip to allow for easy pick up from flat surfaces and faster initial threading. Light-heavy cross section, 8.1" (206mm) length. Made of Weather Resistant Nylon 6.6 with high resistance to ultraviolet light, are black in color and come in packages of 50.
Panduit PLT2H-L0 Cable Tie, 8.1 L (206mm), Light-heavy, Weather-resistant, Black
Specifications
Specifications
Panduit - PLT2H-L0 - Product Categories
- Wire Routing, Management & Protection
- Cable Ties & Wire Ties
Panduit - PLT2H-L0 - Specifications
| Brand Name | Panduit |
|---|---|
| Manufacturer Part Number | PLT2H-L0 |
| Item Description | Pan-Ty PLT2H-L0 Cable Tie, Black, UV PA6.6, 8.1"L, 120lb, PK50 |
| Product Type | Premium Cable Tie |
| Color | Black |
| Environment | Indoor/Outdoor |
| Material | Weather Resistant Nylon 6.6 |
| Resistance Properties | UV Resistant |
| Overall Length (In.) | 8.1 |
| Overall Length (mm) | 206 |
| Body Width (In.) | 0.3 |
| Body Width (mm) | 7.6 |
| Body Thickness (In.) | 0.075 |
| Body Thickness (mm) | 1.9 |
| Maximum Bundle Diameter (In.) | 2 |
| Maximum Bundle Diameter (mm) | 51 |
| Minimum Bundle Diameter (In.) | 0.188 |
| Minimum Bundle Diameter (mm) | 4.8 |
| Minimum Loop Tensile Strength (N) | 534 |
| Minimum Loop Tensile Strength (lb) | 120 |
| Maximum Operating Temperature (°C) | 85 |
| Maximum Operating Temperature (°F) | 185 |
| Minimum Operating Temperature (°C) | -60 |
| Minimum Operating Temperature (°F) | -76 |
| Minimum Installation Temperature (°C) | -20 |
| Minimum Installation Temperature (°F) | -4 |
| Standards Met | UL 62275 Compliant (Type 2, 21), UL Recognized (File #E56854), CSA Certified, RoHS Compliant |
| For Use With | GTH-E, GS4H-E, GS4EH-E, PTH, STH2, ST3EH |
| Part Features | One piece construction provides consistent, reliable performance. Low thread force. |
| Cable Tie Diameter | 8" |
| Type | CABLES TIES AND ACCESSORIES |
| UNSPSC Code | 39121703 |
Panduit - PLT2H-L0 - Package Information
| UPC | 07498354156 |
|---|---|
| Standard Package Quantity | 50 |
| Standard Package Volume (cf) | 0.0321 |
| Standard Ctn. Quantity | 500 |
| Standard Ctn. Volume (cf) | 0.3207 |
