Panduit PLT2S-M120 | Pan-Ty PLT2S-M120 Cable Tie, Black, UV Nylon 12, 7.4"L, 40lb, PK1000
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Panduit PLT2S-M120 | Pan-Ty PLT2S-M120 Cable Tie, Black, UV Nylon 1...
Description
Description
Panduit PLT2S-M120 Locking Cable Ties are designed to satisfy the needs of solar applications and resistance to corrosive elements such as zinc chloride applications, while delivering consistent performance and reliability. Featuring a curved tip to allow for easy pick up from flat surfaces and faster initial threading. Standard cross section, 7.4" (188mm) length. Made of Weather Resistant Nylon 12 with high resistance to ultraviolet light, are black in color and come in packages of 1000.
Panduit - PLT2S-M120 - Features
- For high moisture, corrosive (zinc chloride and dilute acids) and low temperature indoor or outdoor applications
- One-piece construction for consistent performance and reliability
- Lowest threading force of any one-piece cable tie in the industry
- Curve tip design on Intermediate and Standard cross section cable ties is easy to pick up from flat surfaces and allows faster initial threading to speed installation
- Specification Description
- Locking Tie
- Material: Weather-resistant Nylon 12
- Color: Black
- Cross Section: Standard
- Loop Tensile Strength: 40 lb (178 N) Minimum
- Continuous Use Temperature Range: -76 to 194 deg F (-60 to 90 deg C)
- Plenum: No
- Tool: GTS, GTSL, GS2B, GTH, GS4H, PTS, PTH, PPTS, STS2, STH2
- Bundle Diameter: 0.06 - 1.88 Inch (1.5 - 48 mm)
- Environment: Outdoor (UV Resistant)
- Dimension: 7.4 Inch Length x 0.19 Inch Width x 0.052 Inch Thickness (188 mm x 4.8 mm 1.3 mm)
Specifications
Specifications
Panduit - PLT2S-M120 - Product Categories
- Wire Routing, Management & Protection
- Cable Ties & Wire Ties
Panduit - PLT2S-M120 - Specifications
| Brand Name | Panduit |
|---|---|
| Manufacturer Part Number | PLT2S-M120 |
| Item Description | Pan-Ty PLT2S-M120 Cable Tie, Black, UV Nylon 12, 7.4"L, 40lb, PK1000 |
| Product Type | Premium Cable Tie |
| Color | Black |
| Environment | Indoor/Outdoor |
| Material | Weather Resistant Nylon 12 |
| Resistance Properties | UV Resistant |
| Overall Length (In.) | 7.4 |
| Overall Length (mm) | 188 |
| Body Width (In.) | 0.19 |
| Body Width (mm) | 4.8 |
| Body Thickness (In.) | 0.052 |
| Body Thickness (mm) | 1.3 |
| Maximum Bundle Diameter (In.) | 1.88 |
| Maximum Bundle Diameter (mm) | 48 |
| Minimum Bundle Diameter (In.) | 0.06 |
| Minimum Bundle Diameter (mm) | 1.5 |
| Minimum Loop Tensile Strength (N) | 178 |
| Minimum Loop Tensile Strength (lb) | 40 |
| Maximum Operating Temperature (°C) | 90 |
| Maximum Operating Temperature (°F) | 194 |
| Minimum Operating Temperature (°C) | -60 |
| Minimum Operating Temperature (°F) | -76 |
| Minimum Installation Temperature (°C) | -20 |
| Minimum Installation Temperature (°F) | -4 |
| Standards Met | RoHS Compliant |
| For Use With | GTS-E, GS2B-E, GTH-E, GS4H-E, PTS, PTH, PPTS, STS2, STH2 |
| Part Features | One-piece locking wedge for consistent performance and reliability. Low thread force and high loop tensile strength. |
Panduit - PLT2S-M120 - Package Information
| UPC | 07498355003 |
|---|---|
| Standard Package Quantity | 1000 |
| Standard Package Volume (cf) | 0.2164 |
| Standard. Ctn. Quantity | 10000 |
| Standard. Ctn. Volume (cf) | 2.1638 |
Panduit - PLT2S-M120 - Videos
| Video 1 | Click to View |
|---|
