Panduit PUFP6X04WH-UG | Copper Cable | UPC - 07498339798
Description
Description
Panduit Category 6A UTP copper cabling system utilizes patent pending MaTriX Technology in the cable and patch cords along with advanced connector compensation techniques to achieve channel bandwidth performance above industry standard requirements. Fully compliant up to 100 m, the cabling system significantly reduces cost of ownership by eliminating the need for field testing for alien crosstalk, improving energy efficiencies with better airflow management, and allows for the implementation of advanced Power over Ethernet (PoE) applications. The complete Category 6A cabling system offers both reliable 10 Gb Ethernet performance and the highest density infrastructure solution available.
Panduit TX6A 10Gig Shielded Copper Cable, Cat6a U/FTP, 80 VAC, 4 Pair Conductors, Copper Conductor, 23 AWG Conductor, 0.29 in OD, 1000 ft Length, <8.9 Ohm Resistance, FEP Insulation, PVC Jacket, White Jacket, -4 to 140 deg F
Features + Benefits
- Cross divider, reduced attenuation, easy payout carton, tested beyond the standards and descending length cable markings
- Each individual twisted pair includes a metallic foil shield and is protected by a low smoke, flame retardant PVC jacket
Panduit PUFP6X04WH-UG | Copper Cable | UPC - 07498339798 Key Specs
| Performance Level | Category 6A |
| Cable Construction | U/FTP |
| Flammability Rating | Riser(CMR) |
| Resistance Properties | Flame Retardant |
| Jacket Material | Polyvinyl Chloride |
| Nominal Cable Outside Diameter (In.) | 0.31 |
| Nominal Cable Outside Diameter (mm) | 7.9 |
| Maximum Operating Temperature (°C) | 90 |
| Maximum Operating Temperature (°F) | 194 |
| Minimum Operating Temperature (°C) | -10 |
| Minimum Operating Temperature (°F) | 14 |
| Maximum Installation Temperature (°C) | 60 |
| Maximum Installation Temperature (°F) | 140 |
| Minimum Installation Temperature (°F) | 32 |
| Sub Brand | PanNet |
| Maximum Installation Tension (lb) | 25 |
| Maximum Installation Tension (N) | 110 |
Panduit PUFP6X04WH-UG | Copper Cable | UPC - 07498339798 Data Sheets
| Selection Guides | TX6A 10Gig Shielded Copper Cabling System Selection Guide: COSG06--WW-ENG | Download and View |
| Technical References | Extended Reach over Copper Cable: TR124 | Download and View |
| Technology Briefs | Decision to Install Cat 6A: COTB04--WW-ENG | Download and View |
Panduit PUFP6X04WH-UG | Copper Cable | UPC - 07498339798 Environmental Information
| Panduit's RoHS Statement | Download and View |
