Panduit PUP6004YL-WZ | Cat6A U/UTP Copper Cable, CMP Rated, Yellow
Regular price
$1.45
Unit price
Brand: Panduit
|
SKU:
CMP-00423PND-6ATX-05
Regular price
$1.45
Unit price
Description
Description
Panduit PUP6004YL-WZ | Cat6A U/UTP Copper Cable, CMP Rated, Yellow
Enhanced electrical headroom performance provides our enhanced Cat 6 U/UTP copper cable margin above industry standards and exceptional performance for PoE++ applications.
Specifications
Specifications
Panduit - PUP6004YL-WZ - Specifications
| Note | Available in North America |
|---|---|
| Performance Level | Category 6 |
| Cable Construction | U/UTP |
| Flammability Rating | Plenum (CMP) |
| Resistance Properties | Flame-Retardant |
| Jacket Material | Polyvinyl Chloride (PVC) |
| Nominal Cable Outside Diameter (In.) | 0.225 |
| Nominal Cable Outside Diameter (mm) | 5.7 |
| Maximum Operating Temperature (°C) | 75 |
| Maximum Operating Temperature (°F) | 167 |
| Minimum Operating Temperature (°C) | -20 |
| Minimum Operating Temperature (°F) | -4 |
| Maximum Installation Temperature (°C) | 50 |
| Maximum Installation Temperature (°F) | 122 |
| Minimum Installation Temperature (°C) | 0 |
| Minimum Installation Temperature (°F) | 32 |
| Sub Brand | Pan-Net® |
| Maximum Installation Tension (N) | 110 |
| Maximum Installation Tension (lb) | 25 |
| Number of Pairs | 4 |
| Conductor Material | Copper |
Panduit - PUP6004YL-WZ - Package Includes
| UPC | 61305689573 |
|---|---|
| Std. Pkg. Qty. | 1000 |
| Std. Pkg. Volume (cf) | 1.7315 |
| Std. Ctn. Qty. | 36000 |
| Std. Ctn. Volume (cf) | 62.3333 |
