Description
Description
PUP6AM04WH-UGA Copper cable category 6A U/UTP plenum (CMP) 4-pair conductors are 23 AWG with FEP insulation twisted in pairs separated by an integrated pair divider surrounded by an advancedmatrix tape and protected by a flame-retardant PVC jacket white.
Features + Benefits
Panduit PUP6AM04WH-UGA | Copper Cable | UPC - 61305614289 Key Specs
| Note | Available in Latin America and Asia Pacific |
| Environment | Indoor |
| Performance Level | Category 6A |
| Cable Construction | U/UTP |
| Flammability Rating | Plenum (CMP) |
| Resistance Properties | Flame Retardant |
| Jacket Material | Polyvinyl Chloride |
| Nominal Cable Outside Diameter (In.) | 0.28 |
| Nominal Cable Outside Diameter (mm) | 7.1 |
| Maximum Operating Temperature (°C) | 75 |
| Maximum Operating Temperature (°F) | 167 |
| Minimum Operating Temperature (°C) | -20 |
| Minimum Operating Temperature (°F) | -4 |
| Maximum Installation Temperature (°C) | 60 |
| Maximum Installation Temperature (°F) | 140 |
| Minimum Installation Temperature (°F) | 32 |
| Sub Brand | PanNet |
| Maximum Installation Tension (lb) | 25 |
Panduit PUP6AM04WH-UGA | Copper Cable | UPC - 61305614289 Data Sheets
| Technology Briefs | Decision to Install Cat 6A: COTB04--WW-ENG | Download and View |
| Technology Briefs | Power over Ethernet ?????????????????? | Download and View |
| Application Guides | Plenum Network Infrastructure for In-Ceiling Applications: COAG01 | Download and View |
Panduit PUP6AM04WH-UGA | Copper Cable | UPC - 61305614289 Environmental Information
| Panduit's RoHS Statement | Download and View |
