Panduit PUP6AS04WH-G | Copper Cable | UPC - 61305636314

Panduit PanNet TX6A 10Gig Copper Cable, Cat 6a UTP Plenum, 4 Pair Conductors, Solid Conductor, 23 AWG Conductor, 1/4 in OD, 1000 ft Length, <9.38 Ohm Resistance, FEP/PE Insulation, FEP Jacket, White Jacket, -4 to 194 deg F

Features + Benefits

• Copper conductors shall be twisted in pairs and separated by a cross divider, all four pairs shall be surrounded by a non-conductive foil tape and a flame retardant jacket
• Compatible with components of the TX6A-SD 10Gig UTP copper cabling system with MaTriX technology (70 m solution) for increased design flexibility
• Provides margin above the industry standard for both electrical and alien crosstalk performance
• Improves fill capacity, cable management, reduces required bend radius and allows efficient use of pathways and spaces
• Allows operation in 194 deg F ambient environment providing error-free performance in high density cabinets and large cable bundles running PoE+ or PoE++ applications
• All testing and headroom based on 48-port/1RU panels
• Easy identification of remaining cable reduces installation time and cable scrap
• <9.38 Ohm per 328 ft

Panduit PUP6AS04WH-G | Copper Cable | UPC - 61305636314 Key Specs

---

Panduit PUP6AS04WH-G | Copper Cable | UPC - 61305636314 Data Sheets

Specification Sheets | Category 6A UTP Copper Cable	Download and View
Flyers | Category 6A UTP Guaranteed Headroom Platform North America	Download and View
Certificate | Test Verification of Conformity - GFT?OP?11a	Download and View

---

Panduit PUP6AS04WH-G | Copper Cable | UPC - 61305636314 Environmental Information

Panduit's RoHS Statement

Download and View
