Description
Description
Panduit PUR6004WH-UY | Tx6000 Copper Cable, Cat 6, 23 Awg, U/Utp, Cmr, White
The TX6000 Cat 6 U/UTP Riser copper cable is constructed of 23 AWG copper conductors with HDPE insulation. The copper conductors shall be twisted in pairs and separated by a cross divider. All four pairs shall be covered by a flame retardant PVC (CMR), White jacket. Packaged 1000 ft./305m on a reel in a box.
Panduit - PUR6004WH-UY - Features
- High performance Category 6 riser (CMR) 4-pair UTP copper cable. Copper conductors are 23 AWG construction with polyolethin insulation. Conductors are twisted in pairs and placed in a low smoke, flame-retardant PVC jacket.
- Exceeds requirements of ANSI/TIA/EIA-568-C.2 Category 6 and ISO 11801 2nd Edition Class E channel standards
- Exceeds requirements of ANSI/TIA/EIA-568-C.2 and IEC 61156-5 Category 6 component standards
- Descending length cable markings enable easy identification of remaining cable which reduces installation time and cable scrap
- Cable supplied in an easy payout reel-in-a-box
Specifications
Specifications
Panduit - PUR6004WH-UY - Product Categories
- Copper Systems
- Enterprise/Data Center Copper Cable
Panduit - PUR6004WH-UY - Specifications
| Brand Name | Panduit |
|---|---|
| Manufacturer Part Number | PUR6004WH-UY |
| Item Description | Tx6000 Copper Cable, Cat 6, 23 Awg, U/Utp, Cmr, White |
| Note | Available in North America |
| Environment | Indoor |
| Performance Level | Category 6 |
| Cable Construction | U/UTP |
| Flammability Rating | CMR |
| Sub Brand | Pan-Net |
| Number of Pairs | 4 |
| Conductor Material | Copper |
| Conductor Type | Solid |
| Conductor Gauge (AWG) | 23 |
| Color | White |
| Product Type | Copper Cable |
Panduit - PUR6004WH-UY - Package Information
| UPC | 07498305853 |
|---|---|
| Standard Package Quantity | 1000 |
| Standard Package Volume (cf) | 2.2407 |
| Standard Ctn. Quantity | 27000 |
| Standard Ctn. Volume (cf) | 60.5000 |
