Panduit S050X125VAM | Self-Laminating Label Cassette | UPC - 61305676010

The S050X125VAM Die-Cut Self-Laminating Label Cassette includes both label material and ribbon for easy changeover. Self-laminating adhesive labels for wire/cable identification include a white print-on area and a clear overlaminate. For use with the MP300 printer. Vinyl. 0.50" x 1.25" (12.7 mm x 31.8 mm). Wire/Cable Size Range 12 - 10 AWG. Color Clear/White. 200 labels per cassette. 1 cassette per package.

---

Panduit Panduit S050X125VAM | Self-Laminating Label Cassette | UPC - 61305676010 Key Specs

Note	For use with MP300 printer
Product Type	Self-Laminating Label Cassette
Color	White
Compatible Wire Gauge (AWG)	12-10
Material	Vinyl
Number of Labels per Cassette	200
Standards Met	RoHS Compliant
Minimum Cable Diameter (In.)	0.12
Minimum Cable Diameter (mm)	3.1
Maximum Cable Diameter (In.)	0.28
Maximum Cable Diameter (mm)	7
Label Height (In.)	1.25
Label Height (mm)	31.8
Label Width (In.)	0.5
Label Width (mm)	12.7
Minimum Operating Temperature (°C)	-40
Minimum Operating Temperature (°F)	-40
Maximum Operating Temperature (°C)	66
Maximum Operating Temperature (°F)	150
