Brand: Panduit
|
SKU:
342804
Panduit S100X150VHTY | S100X150VHTY Self-Laminating Label
Regular price
$358.29
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Panduit S100X150VHTY | S100X150VHTY Self-Laminating Label
Regular price
$358.29
Unit price
Description
Description
Panduit S100X150VHTY | S100X150VHTY Self-Laminating Label
The thermal transfer self-laminating adhesive label is made of vinyl and is supplied on a roll with 4 labels per row. The label has a red colored print-on area 0.5" (12.7 mm) high for Category 5e UTP, Category 6 UTP, Category 6e UTP, Category 5e FTP, 10 - 6 AWG wires, and a clear overlaminate. It is 1" wide and 1.5" long (25.4 x 38.1 mm) with a 3" (76.2mm) core. It comes in packages of 5000.
Panduit - S100X150VHTY - Features
- Red print-on area, vinyl label for Cat. 5e/Cat. 6/Cat. 6A cables.
- Self-laminating adhesive labels supplied on rolls, include a colored print-on area and clear overlaminate
- Use with Panduit RMH4BL hybrid thermal transfer ribbon
Specifications
Specifications
Panduit - S100X150VHTY - Product Categories
- Signs, Labels & Identification
- Desktop Printer Labels
Panduit - S100X150VHTY - Specifications
| Brand Name | Panduit |
|---|---|
| Manufacturer Part Number | S100X150VHTY |
| Item Description | S100X150VHTY Self-Laminating Label |
| Note | For use with TDP printers |
| Product Type | Self-Laminating Label |
| Cable Type | Category 5e UTP;Category 6 UTP;Category 6A UTP; Category 5e FTP |
| Color | Red |
| Material | Vinyl |
| Printer Type | Thermal Transfer |
| Standards Met | RoHS Compliant, UL969 recognized, File # MH14979; cUL recognized, C22.2 No. 0.15-01, File # MH14979 |
| Compatible Wire Gauge (AWG) | 10 – 6 |
| Maximum Cable Diameter (In.) | 0.32 |
| Maximum Cable Diameter (mm) | 8.1 |
| Minimum Cable Diameter (In.) | 0.16 |
| Minimum Cable Diameter (mm) | 4.1 |
| Maximum Operating Temperature (°C) | 65 |
| Maximum Operating Temperature (°F) | 150 |
| Minimum Operating Temperature (°C) | -40 |
| Minimum Operating Temperature (°F) | -40 |
| Number of Labels | 5 |
| Overall Length (In.) | 1.5 |
| Overall Length (mm) | 38.1 |
| Overall Width (In.) | 1 |
| Overall Width (mm) | 25.4 |
| Print-On Area Height (In.) | 0.5 |
| Print-On Area Height (mm) | 12.7 |
| Label Application | Cable & Wire Marking |
Panduit - S100X150VHTY - Package Information
| UPC | 07498368017 |
|---|---|
| Standard Package Quantity | 5000 |
| Standard Package Volume (cf) | 0.7439 |
| Standard. Ctn. Quantity | 0 |
| Standard. Ctn. Volume (cf) | 0.0000 |
