Panduit S2-38R-X | Ring Terminal,1-2 AWG,3/8in Stud,PK10
Regular price
$6.29
Unit price
Brand: Panduit
|
SKU:
315896-EA
Regular price
$6.29
Unit price
Description
Description
Panduit S2-38R-X | Ring Terminal,1-2 AWG,3/8in Stud,PK10
Tublular Ring Terminal, 2 and 1 AWG, 3/8 stud size, non-insulated, standard package.
Panduit S2-38R-X - TERMINAL-RING - #2 THRU #1 AWG TUBULAR
Specifications
Specifications
Panduit - S2-38R-X - Product Categories
- Wire Termination
- Mechanical & Compression Lugs & Splices
Panduit - S2-38R-X - Specifications
| Brand Name | Panduit |
|---|---|
| Manufacturer Part Number | S2-38R-X |
| Item Description | Ring Terminal,1-2 AWG,3/8in Stud,PK10 |
| Maximum Wire Size (AWG) | 1 - 2 AWG |
| Product Type | Loose Piece Ring Terminal |
| Base Material | Copper |
| Stud Hole Size (In.) | 3/8 |
| Tongue Thickness (In.) | 0.11 |
| Tongue Thickness (mm) | 2.8 |
| Tongue Width (In.) | 0.7 |
| Tongue Width (mm) | 17.8 |
| Overall Length (In.) | 1.7 |
| Overall Length (mm) | 43.2 |
| Overall Width (In.) | 0.7 |
| Overall Width (mm) | 17.8 |
| Barrel Type | Seamless Tubular |
| Barrel Length (In.) | 0.59 |
| Barrel Length (mm) | 15 |
| Insulation Material | Non-Insulated |
| Finish/Coating | Tinned |
| Sub Brand | Pan-Lug |
| Wire Strip Length (In.) | 5/8 |
| Wire Strip Length (mm) | 15.875 |
| Part Features | Seamless tubular barrel provides a consistent high performance quality crimp, Round double thick toungue for reliable power applications, Barrel of terminal internally beveled to provide quick and easy wire insertion, Inspection window allows visual inspection of proper wire insertion. |
Panduit - S2-38R-X - Package Information
| UPC | 07498359881 |
|---|---|
| Standard Package Quantity | 10 |
| Standard Package Volume (cf) | 0.0617 |
| Standard Ctn. Quantity | 0 |
| Standard Ctn. Volume (cf) | 0.0000 |
Panduit - S2-38R-X - Videos
| Video 1 | Click to View |
|---|---|
| Video 2 | Click to View |
