Panduit S200X400VATY | Self-Laminating Label | UPC - 07498343989
Regular price
$1.72
Unit price
Brand: Panduit
|
SKU:
1052593
Regular price
$1.72
Unit price
Description
Description
Panduit Pan-Code Label, Adhesive Blank Self-Laminating, 4 in Length, 2 in W, White, Polyester, For Use With: Dot Matrix Printer and Thermal Transfer Printer
Features + Benefits
- For cat 6 FTP, cat 6A (10 Gig) UTP, cat 6A (10 Gig) FTP, 8 to 4 AWG wires and a clear overlaminate
- The label has a print-on area 3/4 in H
Panduit S200X400VATY Key Specs
| Note | S200X400VATY replaces TTSL18TC3-1 , TTSL18VC3-1 , TTSL59TC3-1 , TTSL7PO3-1 and TTSL7VC3-1. For use with TDP printers. |
| Product Type | Self-Laminating Label |
| Color | White |
| Material | Vinyl |
| Printer Type | Thermal Transfer |
| Standards Met | RoHS Compliant, UL969 recognized, File # MH14979; cUL recognized, C22.2 No. 0.15-01, File # MH14979 |
| Sub Brand | Pan-Code |
| Compatible Wire Gauge (AWG) | 2 – 1 |
| Maximum Cable Diameter (In.) | 0.95 |
| Maximum Cable Diameter (mm) | 24.3 |
| Minimum Cable Diameter (In.) | 0.32 |
| Minimum Cable Diameter (mm) | 8.1 |
| Maximum Operating Temperature (°C) | 66 |
| Maximum Operating Temperature (°F) | 150 |
| Minimum Operating Temperature (°C) | -40 |
| Minimum Operating Temperature (°F) | -40 |
| Number of Labels | 1000 |
| Overall Length (In.) | 4 |
| Overall Length (mm) | 101.6 |
| Overall Width (In.) | 2 |
| Overall Width (mm) | 50.8 |
| Print-On Area Height (In.) | 1 |
| Print-On Area Height (mm) | 25.4 |
Panduit S200X400VATY Data Sheets
| Part Drawings | Part Drawing - PDF - C10468 | Download and View |
| Line Cards | Thermal Transfer Labels DEU | Download and View |
| Line Cards | Thermal Transfer Labels FRA | Download and View |
| Line Cards | Thermal Transfer Labels ITA | Download and View |
| Line Cards | Thermal Transfer Labels Line Card: IDLC08--SA | Download and View |
| Data Sheets | Self-Laminating Translucent Vinyl Film Data Sheet GMV17 | Download and View |
