Description
Description
Panduit Pan-Term Splices are designed and manufactured for fast assembly, and long reliable performance. As the demand for splices increases, it becomes essential to provide a complete system for termination products. We provide an extensive line of tooling designed specifically to provide optimum performance when used as a system for terminating.
Panduit Pan-Lug Pan-Term Butt Splice, Compression, Series: SCS, Stranded Copper Conductor, 300 kcmil Conductor, 2-1/4 in Length, 0.65 in ID x 0.81 in OD Barrel, 35 kV, Specifications: 1-1/16 in L Wire Strip, Standard Barrel Configuration, 90 deg C, Copper, White, Electro Plated Tin
Features + Benefits
- Color coded barrels marked with Panduit and specified competitor die index numbers for proper crimp die selection
- Internal wire stops to prevent over insertion of conductor
- Tin plated to inhibit corrosion
Panduit SCS300-X | Compression Connectors - Splices | UPC - 07498390350 Key Specs
| Product Type | Compression Connectors - Splices |
| Sub Brand | Pan-Lug |
| Copper Conductor Size (AWG) | 6/0 |
| Copper Conductor Size (kcmil) | 336.4 |
| Color Code | White |
| Burndy Die Index Number | 17 |
| Panduit Die Index Number | P66 |
| Overall Length (In.) | 2.25 |
| Overall Length (mm) | 57.2 |
| Wire Strip Length (In.) | 1.0625 |
| Wire Strip Length (mm) | 27 |
Panduit SCS300-X | Compression Connectors - Splices | UPC - 07498390350 Data Sheets
| Catalog Cut Sheets | Catalog Cut Sheet - SCS6-L Product Page | Download and View |
| Selection Guides | Power Connector Tool and Die Selection Guides | Download and View |
| Part Drawings | SCS Standard Barrel 300 Kcmil - 1000 Kcmil Copper Splices | Download and View |
Panduit SCS300-X | Compression Connectors - Splices | UPC - 07498390350 Environmental Information
| Panduit's RoHS Statement | Download and View |
