Panduit SCS500-6 | Pan-Lug SCS500-6 Compression Connectors - Splices
Regular price
$132.24
Unit price
Brand: Panduit
|
SKU:
330374
Regular price
$132.24
Unit price
Description
Description
Panduit SCS500-6 | Pan-Lug SCS500-6 Compression Connectors - Splices
Copper butt splice, standard barrel, 500 kcmil cable.
Panduit - SCS500-6 - Features
- Panduit - Butt splice - brown - SCS500-6.
- General Information
- Weight (lb)
- 1.98
Specifications
Specifications
Panduit - SCS500-6 - Product Categories
- Wire Termination
- Splices
Panduit - SCS500-6 - Specifications
| Brand Name | Panduit |
|---|---|
| Manufacturer Part Number | SCS500-6 |
| Item Description | Pan-Lug SCS500-6 Compression Connectors - Splices |
| Product Type | Compression Connectors - Splices |
| Sub Brand | Pan-Lug |
| Copper Code Conductor Size (kcmil) | 500 |
| Barrel Type | Standard |
| Maximum Voltage (kV) | 35 |
| Base Material | Copper |
| Finish/Coating | Tin-Plated |
| Color Code | Brown |
| Burndy Die Index Number | 20 |
| Panduit Die Index Number | P87 |
| Overall Length (In.) | 2.87 |
| Overall Length (mm) | 72.9 |
| Wire Strip Length (mm) | 34.9 |
| UL Temperature Rating (°C) | 90 |
| Part Features | color coded barrel, internal wire stops,tin plated to inhibit corrosion,NEBS Level 3 |
Panduit - SCS500-6 - Package Information
| UPC | 07498390365 |
|---|---|
| Standard Package Quantity | 6 |
| Standard Package Volume (cf) | 0.0328 |
| Standard Ctn. Quantity | 0 |
| Standard Ctn. Volume (cf) | 0.0000 |
Panduit - SCS500-6 - Videos
| Video 1 | Click to View |
|---|
