Panduit SCS750-6 | Compression Connectors - Splices | UPC - 07498390375
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Panduit SCS750-6 | Compression Connectors - Splices | UPC - 0749839...
Description
Description
Panduit Pan-Term Splices are designed and manufactured for fast assembly, and long reliable performance. As the demand for splices increases, it becomes essential to provide a complete system for termination products. We provide an extensive line of tooling designed specifically to provide optimum performance when used as a system for terminating.
Panduit Pan-Lug Pan-Term Butt Splice, Compression, Series: SCS, Stranded Copper Conductor, 750 kcmil Conductor, 3.37 in Length, 1.03 in ID x 1.29 in OD Barrel, 35 kV, Specifications: 1-5/8 in L Wire Strip, Standard Barrel Configuration, 90 deg C, Copper, Black, Electro Plated Tin
Features + Benefits
- Color coded barrels marked with Panduit and specified competitor die index numbers for proper crimp die selection
- Internal wire stops to prevent over insertion of conductor
- Tin plated to inhibit corrosion
Panduit SCS750-6 | Compression Connectors - Splices | UPC - 07498390375 Key Specs
| Product Type | Compression Connectors - Splices |
| Sub Brand | Pan-Lug |
| Copper Conductor Size (AWG) | 9/0 |
| Copper Conductor Size (kcmil) | 674.6 |
| Color Code | Black |
| Burndy Die Index Number | 24 |
| Panduit Die Index Number | P106 |
| Overall Length (In.) | 3.37 |
| Overall Length (mm) | 85.6 |
| Wire Strip Length (mm) | 41.3 |
Panduit SCS750-6 | Compression Connectors - Splices | UPC - 07498390375 Data Sheets
| Catalog Cut Sheets | Catalog Cut Sheet - SCS6-L Product Page | Download and View |
| Selection Guides | Power Connector Tool and Die Selection Guides | Download and View |
| Part Drawings | SCS Standard Barrel 300 Kcmil - 1000 Kcmil Copper Splices | Download and View |
Panduit SCS750-6 | Compression Connectors - Splices | UPC - 07498390375 Environmental Information
| Panduit's RoHS Statement | Download and View |
