Panduit SCSF6-L | Compression Connectors - Splices | UPC - 07498355679
Description
Description
Panduit Pan-Term Splices are designed and manufactured for fast assembly, and long reliable performance. As the demand for splices increases, it becomes essential to provide a complete system for termination products. We provide an extensive line of tooling designed specifically to provide optimum performance when used as a system for terminating.
Panduit Pan-Lug Pan-Term Butt Splice, Compression, Series: SCSF, Copper Conductor, 6 AWG Conductor, 1-3/4 in Length, Flared/Seamless Barrel, 0.22 in ID x 0.31 in OD Barrel, 35 kV, Specifications: 13/16 in L Wire Strip, Standard Barrel Configuration, 90 deg C, Copper, Blue, Electro Plated Tin
Features + Benefits
- Color coded barrels marked with Panduit die index numbers for proper crimp die selection
- Internal wire stops to prevent over insertion of conductor
- Tin plated to inhibit corrosion
Panduit SCSF6-L | Compression Connectors - Splices | UPC - 07498355679 Key Specs
| Product Type | Compression Connectors - Splices |
| Sub Brand | Pan-Lug |
| Copper Conductor Size (AWG) | 26.25 |
| Copper Conductor Size (kcmil) | 26.25 |
| Color Code | Blue |
| Panduit Die Index Number | P24 |
| Overall Length (In.) | 1.75 |
| Overall Length (mm) | 44.5 |
| Wire Strip Length (mm) | 20.6 |
Panduit SCSF6-L | Compression Connectors - Splices | UPC - 07498355679 Data Sheets
| Catalog Cut Sheets | Catalog Cut Sheet - SCSF8-L Product Page | Download and View |
| Part Drawings | Part Drawing - PDF - C41158_02 | Download and View |
| Selection Guides | Power Connector Tool and Die Selection Guides | Download and View |
Panduit SCSF6-L | Compression Connectors - Splices | UPC - 07498355679 Environmental Information
| Panduit's RoHS Statement | Download and View |
