Panduit SE50P-CR8 | Braided Expandable Sleeving
Description
Description
Enhance cable protection and organization with our braided sleeving. Its expandable design and flame-retardant properties, provides heat and humidity resistance in demanding environments.
Braided Expandable Sleeving, 0.50" diameter (12.7mm), provides continuous abrasion resistance for wires, cables and tubing. The highly flexible open weave will not trap heat or humidity, gray, Polyethylene Terephthalate, 100 ft. per reel.
Panduit Braided Sleeve, Expandable, 1/2 in Sleeve Diameter, 100 ft Sleeve Length, 1/4 to 3/4 in Diameter Cable, -94 to 257 deg F, Flammability: HB, Polyethylene Terephthalate, Gray
Panduit - SE50P-CR8 - Features
- Provides continuous abrasion protection for wires, cables, hoses and tubing
- Highly flexible open weave will not trap heat or humidity
- Allows for use with irregular shapes
- Lightweight durable protection
Specifications
Specifications
Panduit - SE50P-CR8 - Specifications
| Brand Name | Panduit |
|---|---|
| Manufacturer Part Number | SE50P-CR8 |
| Decimal | .500 Inch |
| Dual | No |
| Heat Shrink | No Is Not Shrink Tubing |
| Mil Spec | No |
| Material/Type | Pe-Polyethylene |
| Military Color Code | Gray (Grey) |
| Size By Inch Fractions | 1/2 Inch |
| Sleeving | Yes |
| Spiral Wrap | No |
| Ul | Yes |
| Zipper | No |
| UNSPSC Code | 39121723 |
| Application | (1) Provides Continuous Abrasion Protection for Wires, Cables, Hoses, and Tubing; (2) Highly Flexible Open Weave will not Trap Heat or Humidity; (3) Allows for Use with Irregular Shapes |
| Material | PET |
| Flammability Rating | UL94V-0 |
| Color | Gray |
| Resistance Properties | Abrasion-Resistant, UV-Resistant (20-Year) |
| Standards Met | CSA Certified, UL 94 V-0 Rated, UL Recognized E116868, RoHS Compliant |
| Maximum Diameter (In.) | 0.75 |
| Maximum Diameter (mm) | 19.1 |
| Maximum Operating Temperature (°C) | 125 |
| Maximum Operating Temperature (°F) | 257 |
| Minimum Operating Temperature (°C) | -70 |
| Minimum Operating Temperature (°F) | -94 |
| Nominal Diameter (In.) | 0.5 |
| Nominal Diameter (mm) | 12.7 |
| Overall Length (ft.) | 100 |
| Overall Length (m) | 30.5 |
| Product Type | Braided Expandable Sleeving |
| Maximum Bundle Diameter (In.) | 0.75 |
| Maximum Bundle Diameter (mm) | 19.1 |
| Minimum Bundle Diameter (In.) | 0.25 |
| Minimum Bundle Diameter (mm) | 6.4 |
| UPC | 07498337012 |
Panduit - SE50P-CR8 - Environmental Information
| RoHS Status | ROHS3 Compliant |
|---|---|
| Moisture Sensitivity Level (MSL) | Not Applicable |
| ECCN | EAR99 |
| HTSUS | 7413.00.5000 |
Panduit - SE50P-CR8 - Videos
| Panduit SE50P-CR8 Video 1 | Click to View |
|---|
