Panduit SE50PFR-DR8 | Pan-Wrap Braided Sleeving | UPC - 07498322000

Braided Expandable Sleeving, 0.50" diameter (12.7mm), provides continuous abrasion resistance for wires, cables and tubing. The highly flexible open weave will not trap heat or humidity, gray, Flame Retardant, Polyethylene Terephthalate, 500 ft. per reel.

---

Panduit Panduit SE50PFR-DR8 | Pan-Wrap Braided Sleeving | UPC - 07498322000 Key Specs

Application	(1) Provides Continuous Abrasion Protection for Wires, Cables, Hoses, and Tubing; (2) Highly Flexible Open Weave will not Trap Heat or Humidity; (3) Allows for Use with Irregular Shapes
Material	Polyethylene Terephthalate
Flammability Rating	VW-1
Color	Gray
Resistance Properties	Flame-Retardant
Standards Met	CSA Certified, Compliant with U.S. and European passenger rail standards, UL Recognized E116868; RoHS Complaint
Maximum Operating Temperature (°C)	125
Minimum Operating Temperature (°C)	-70
Maximum Operating Temperature (°F)	257
Minimum Operating Temperature (°F)	-94
Nominal Diameter (In.)	0.5
Nominal Diameter (mm)	12.7
Overall Length (ft.)	500
Overall Length (m)	152.4
Product Type	Pan-Wrap Braided Sleeving
Part Features	Provides continuous abrasion protection for wires, cables, hoses and tubing. Highly flexible open weave will not trap heat or humidity, allows for irregular shapes. Lightweight and durable protection. Complaint with U.S. and European passenger rail standards.
