Panduit T19R-CY | Spiral Wrap | UPC - 07498339667
Regular price
$113.51
Unit price
Brand: Panduit
|
SKU:
1035416
Regular price
$113.51
Unit price
Description
Description
Panduit Spiral Wrap, 0.19 in OD Dia, 100 ft Length, 0.035 in Thickness, 1 in Maximum Bundle Dia, 1/8 in Minimum Bundle Dia, -40 to 122 deg F, Polyethylene, Natural
Features + Benefits
- Harness multiple cable into a single manageable bundle
- Allows breakouts of single/multiple cable
- Reverse cut
- Multiple color allow easy identification of cable bundle
- Installation tool supplied in each package
- Reusable
- Made of fire resistant polyethylene
Panduit T19R-CY Key Specs
| Application | (1) Harness Multiple Cables Into a Single Manageable Bundle (2) Allows Breakouts of Single/Multiple Cables (3) Provides Abrasion Protection for Wire, Cables, Hoses, and Tubing |
| Note | T19R-CY replaces T19R-C |
| Product Type | Spiral Wrap |
| Color | Natural |
| Flammability Rating | V-2 |
| Includes | Installation Tool |
| Material | Polyethylene |
| Resistance Properties | Fire Resistant |
| Maximum Bundle Diameter (In.) | 1 |
| Maximum Bundle Diameter (mm) | 25.4 |
| Maximum Operating Temperature (°C) | 50 |
| Maximum Operating Temperature (°F) | 122 |
| Minimum Bundle Diameter (In.) | 0.12 |
| Minimum Bundle Diameter (mm) | 3.2 |
| Minimum Operating Temperature (°C) | -40 |
| Minimum Operating Temperature (°F) | -40 |
| Outer Diameter (In.) | 0.19 |
| Outer Diameter (mm) | 4.8 |
| Overall Length (ft.) | 100 |
| Overall Length (m) | 30.5 |
| Standards Met | UL Recognized E141152 |
| Wall Thickness (In.) | 0.03 |
| Wall Thickness (mm) | 0.8 |
| Part Features | Allows breakouts of single/multiple cables, Provides abrasion protection for wire, cables, hoses and tubing. Multiple colors allow for easy identification of cable bundles. Installation tool is supplied and the spiral wrap is reusable. |
Panduit T19R-CY Data Sheets
| Part Drawings | Part Drawing - PDF - GB0239LQ_02-5-23-11 | Download and View |
| Part Drawings | Spiral Wrap Part Number Set-up Chart: GB0239HA | Download and View |
| Catalog Cut Sheets | Industrial Electrical Solutions | Download and View |
| Line Cards | Wire Abrasion Protection Line Card HSLC1-WW-ENG | Download and View |
