Panduit T25F-C0 | T25F-C0 Spiral Wrap, Black, UV PE, 0.1875" M...
Description
Description
The T25F-C0 Polyethylene Spiral Wrap provides continuous abrasion protection for wires, cables, and tubing. The spiral wrap harnesses multiple cables into a single manageable bundle while allowing for breakouts. Lightweight, flexible, durable protection allows for use with irregular shapes. Rated for use up to 122°F (50°C). 0.25" (6.4 mm) diameter x 100' (30.5 m) long. Bundle Diameter Range 0.1875" to 2" (4.8 mm to 50.8 mm). Color Black.
Specifications
Specifications
Panduit - T25F-C0 - Product Categories
- Wire Routing, Management & Protection
- Cable Sleeves, Tools & Wraps
Panduit - T25F-C0 - Specifications
| Brand Name | Panduit |
|---|---|
| Manufacturer Part Number | T25F-C0 |
| Item Description | T25F-C0 Spiral Wrap, Black, UV PE, 0.1875" Min Dia., 100' Roll, PK1 |
| Application | Harness Multiple Cables Into a Single Manageable Bundle; Allows Breakouts of Single/Multiple Cables; Provides Abrasion Protection for Wire, Cables, Hoses, and Tubing |
| Product Type | Spiral Wrap |
| Color | Black |
| Environment | Indoor and Outdoor |
| Flammability Rating | UL94-HB |
| Material | Weather Resistant Polyethylene |
| Resistance Properties | Abrasion Resistance; Weather Resistant |
| Maximum Bundle Diameter (In.) | 2 |
| Maximum Bundle Diameter (mm) | 50.8 |
| Maximum Operating Temperature (°C) | 50 |
| Maximum Operating Temperature (°F) | 122 |
| Minimum Bundle Diameter (In.) | 0.1875 |
| Minimum Bundle Diameter (mm) | 4.8 |
| Minimum Operating Temperature (°C) | -40 |
| Minimum Operating Temperature (°F) | -40 |
| Outer Diameter (In.) | 0.25 |
| Outer Diameter (mm) | 6.4 |
| Overall Length (ft.) | 100 |
| Overall Length (m) | 30.5 |
| Standards Met | UL Recognized - E141152; UL94HB |
| Wall Thickness (In.) | 0.04 |
| Wall Thickness (mm) | 1.02 |
| Part Features | Allows breakouts of single/multiple cables, Provides abrasion protection for wire, cables, hoses and tubing. Multiple colors allow for easy identification of cable bundles. The spiral wrap is reusable. |
Panduit - T25F-C0 - Package Information
| UPC | 07498370555 |
|---|---|
| Standard Package Quantity | 1 |
| Standard Package Volume (cf) | 0.2695 |
| Standard. Ctn. Quantity | 0 |
| Standard. Ctn. Volume (cf) | 0.0000 |
Panduit - T25F-C0 - Videos
| Video 1 | Click to View |
|---|
