Panduit TM2PWH25-M | Cable Tie Mount, Natural, PA 6.6, Push Barb, 0...
Description
Description
Streamline your cable management with our winged push barb cable tie mount-- no adhesive needed. Ideal for indoor use, it's made from Nylon 6.6 for better strength and stability.
Panduit TM2PWH25-M Winged Push Barb Mounts provide a solution to cable management in situations where only one side of the panel is accessible. They require no adhesive or additional mounting hardware and the wing design provides added stability. For u se in indoor environments and with panels no thicker than 0.11 (2.7mm). Suitable for miniature, intermediate and standard cross-section cable ties. Made of Nylon 6.6, are natural in color and come in packages of 100.
Panduit Cable Tie Mount, Through Hole, Push/Arrow Head Barb Mount, 0.71 in Base Length, 0.61 in Base Width, Nylon 6.6, Natural
Panduit - TM2PWH25-M - Features
- Wing provides added stability
- Requires no adhesive or additional mounting hardware
- Can be used where only one side of the panel is accessible
Specifications
Specifications
Panduit - TM2PWH25-M - Specifications
| Brand Name | Panduit |
|---|---|
| Manufacturer Part Number | TM2PWH25-M |
| Type | Cables Ties And Accessories |
| UNSPSC Code | 39121703 |
| Product Type | Cable Tie Mount |
| Application | Push Barb Cable Tie Mounts Wing Provides Added Stability. Can Be Used Where Only One Side of the Panel is Accessible. |
| Color | Natural |
| Environment | Indoor |
| Material | Nylon 6.6 |
| Maximum Operating Temperature (°C) | 85 |
| Maximum Operating Temperature (°F) | 185 |
| Minimum Operating Temperature (°C) | -60 |
| Minimum Operating Temperature (°F) | -76 |
| Mount Method | Push Barb |
| Overall Length (In.) | 0.71 |
| Overall Length (mm) | 18.1 |
| Overall Width (In.) | 0.61 |
| Overall Width (mm) | 15.5 |
| Overall Height (In.) | 0.72 |
| Overall Height (mm) | 18.3 |
| Standards Met | CE Compliant, UL Recognized:E136577, RoHS Compliant |
| For Use With | Miniature, Intermediate, Standard Cross-Section Ties |
| UPC | 07498322236 |
Panduit - TM2PWH25-M - Videos
| Panduit TM2PWH25-M Video 1 | Click to View |
|---|
