Panduit TM2S8-C86 | TM Cable Tie Mount
Regular price
$83.55
Unit price
Brand: Panduit
|
SKU:
10083572
Regular price
$83.55
Unit price
Description
Description
Panduit TM2S8-C86 | TM Cable Tie Mount
Panduit Pan-Ty Cable Tie Mount, Threaded Mounting, 0.19 in Maximum Tie Width, 0.42 in Base Length, 0.63 in Base Width, Nylon 6.6, Light Blue
Perfect for extreme environments, our winged push barb cable tie mount resist chemicals, radiation, and UV. Ideal for nuclear and chemical plants, they ensure secure cable management indoors or out.
Panduit - TM2S8-C86 - Features
- These small cables minimize waste, optimize cable management, speed deployment and improve flexibility and manageability
- Unique cradle design provides maximum stability for cable bundle
- Low profile design keeps bundle close to mounting surface where overhead space is limited
- Metal impregnated
- For use with miniature, intermediate and standard cable ties
Specifications
Specifications
Panduit - TM2S8-C86 - Specifications
| Material Description | Nylon 6.6 () |
|---|---|
| Product Type | Cable Tie Mount |
| Application | Unique Cradle Design Provides Maximum Stability for the Cable Bundle and Low Profile Design Keeps Bundle Close to Mounting Surface |
| Color | Light Blue |
| Flammability Rating | UL94-HB |
| Environment | Indoor |
| Material | Nylon 6.6 |
| Material Properties | Metal-Impregnated |
| Maximum Operating Temperature (°C) | 85 |
| Maximum Operating Temperature (°F) | 185 |
| Minimum Operating Temperature (°C) | -40 |
| Minimum Operating Temperature (°F) | -40 |
| Mount Method | Screw-On |
| Mounting Hole Thread Size | #8 |
| Overall Length (In.) | 0.63 |
| Overall Length (mm) | 16 |
| Overall Width (In.) | 0.42 |
| Overall Width (mm) | 50.3 |
| Overall Height (In.) | 0.27 |
| Overall Height (mm) | 7 |
| Standards Met | RoHS Compliant |
| UPC | 07498311512 |
Panduit - TM2S8-C86 - Package Information
| UPC | 07498311512 |
|---|---|
| Standard Packaging Quantity | 100 |
| Standard Packaging Volume (cf) | 0.0568 |
| Standard Ctn. Quantity | 500 |
| Standard Ctn. Volume (cf) | 0.2839 |
Panduit - TM2S8-C86 - Videos
| Panduit TM2S8-C86 Videos | Click to View |
|---|
