Panduit TM3S10-C186 | TM Cable Tie Mount
Description
Description
Panduit Pan-Ty Cable Tie Mount, 2-Way Tie Entry, Threaded Mounting, 0.3 in Maximum Tie Width, 0.61 in Base Length, 0.87 in Base Width, Polypropylene, Dark Blue
Perfect for extreme environments, our winged push barb cable tie mount resist chemicals, radiation, and UV. Ideal for nuclear and chemical plants, they ensure secure cable management indoors or out.
Panduit TM3S10-C186 Metal Detectable screw applied cable mounts allow identification by metal detection equipment to help meet food, beverage, and pharmaceutical safety standards. The mounts provide maximum stability and keep cables bundle close to mou nting surface. For use with #10 (M5) screw and Standard or Light-Heavy standard cross section cable ties. They are 0.614" (15.6mm) wide and designed for indoor use. Made of Metal Detectable Polypropylene, are dark blue in color, and come in packages of 100.
Panduit - TM3S10-C186 - Features
- Riser rated patch cords support installations that require this flame rating in specific environments
- 100% performance tested assures that patch cords and pigtails are standard compliant
- QC identification label quality control reference provides lifetime traceability of test data
- Applications: Unique Cradle Design Provides Maximum Stability for the Cable Bundle and Low Profile Design Keeps Bundle Close to Mounting Surface
- Unique cradle design provides maximum stability for cable bundle
- Low profile design keeps bundle close to mounting surface
- Metal impregnated
- For use with standard and light heavy cable ties
Specifications
Specifications
Panduit - TM3S10-C186 - Specifications
| Type | Cables Ties And Accessories |
|---|---|
| UNSPSC Code | 55120000 |
| Technical Information | RoHS Compliant |
| Material Description | Polypropylene (Chemical-Resistant) |
| Product Type | Cable Tie Mount |
| Application | Unique Cradle Design Provides Maximum Stability for the Cable Bundle and Low Profile Design Keeps Bundle Close to Mounting Surface |
| Color | Dark Blue |
| Flammability Rating | UL94-HB |
| Environment | Indoor |
| Material | Polypropylene |
| Material Properties | Metal-Impregnated |
| Maximum Operating Temperature (°C) | 115 |
| Maximum Operating Temperature (°F) | 239 |
| Minimum Operating Temperature (°C) | -40 |
| Minimum Operating Temperature (°F) | -40 |
| Mount Method | Screw-On |
| Mounting Hole Thread Size | #10 |
| Overall Length (In.) | 0.87 |
| Overall Length (mm) | 22 |
| Overall Width (In.) | 0.61 |
| Overall Width (mm) | 50.3 |
| Overall Height (In.) | 0.37 |
| Overall Height (mm) | 9.5 |
| Resistance Properties | Chemical-Resistant |
| UPC | 07498311511 |
Panduit - TM3S10-C186 - Package Information
| UPC | 07498311511 |
|---|---|
| Standard Packaging Quantity | 100 |
| Standard Packaging Volume (cf) | 0.0568 |
| Standard Ctn. Quantity | 500 |
| Standard Ctn. Volume (cf) | 0.2839 |
Panduit - TM3S10-C186 - Videos
| Panduit TM3S10-C186 Videos | Click to View |
|---|
