Brand: Panduit
|
SKU:
10045315
Panduit TV105-12MY | Non-Shrink Tubing | UPC - 07498345238
Regular price
$139.86
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Panduit TV105-12MY | Non-Shrink Tubing | UPC - 07498345238
Regular price
$139.86
Unit price
Description
Description
Panduit Non-Shrink Tubing, 0.089 in ID, 1000 ft Length, 0.016 in Thickness, Polyvinyl Chloride, Clear
Features + Benefits
- Provides insulation and protection for lead wires, wire harness assemblies, soldered joints and components in electrical and electronic equipment
Panduit Panduit TV105-12MY | Non-Shrink Tubing | UPC - 07498345238 Key Specs
| Note | TV105-12MY replaces TV105-12DY |
| Product Type | Non-Shrink Tubing |
| Color | Clear |
| Inside Diameter (In.) | 0.09 |
| Inside Diameter (mm) | 2.3 |
| Material | Polyvinyl Chloride |
| Maximum Operating Temperature (°C) | 105 |
| Maximum Operating Temperature (°F) | 221 |
| Maximum Voltage (V) | 300 |
| Minimum Operating Temperature (°C) | -20 |
| Minimum Operating Temperature (°F) | -4 |
| Nominal Diameter (AWG) | 12 |
| Nominal Diameter (In.) | 0.08 |
| Nominal Diameter (mm) | 2 |
| Overall Length (ft.) | 1000 |
| Overall Length (m) | 304.8 |
| Resistance Properties | Flame-Resistant, Heat-Resistant, Moisture-Resistant, Oil-Resistant |
| Standards Met | CSA C22.2 No. 198.1 (OFT), UL224 VW-1, MIL-I-631, RoHS Complaint |
| Wall Thickness (In.) | 0.02 |
| Wall Thickness (mm) | 0.4 |
Panduit Panduit TV105-12MY | Non-Shrink Tubing | UPC - 07498345238 Data Sheets
| Part Drawings | Part Drawing - PDF - G03597BZ_DC_GB0239LV_00C | Download and View |
| Catalog Cut Sheets | Non-Shrink PVC Tubing (TV105-12MY) | Download and View |
| Line Cards | Wire Abrasion Protection Line Card HSLC1-WW-ENG | Download and View |
Panduit Panduit TV105-12MY | Non-Shrink Tubing | UPC - 07498345238 Environmental Information
| Panduit's RoHS Statement | Download and View |
