Brand: Panduit
|
SKU:
365-011-0400-13
Panduit TV105-3MY | Non-Shrink Tubing
Regular price
$1.70
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Panduit TV105-3MY | Non-Shrink Tubing
Regular price
$1.70
Unit price
Brand: Panduit
|
SKU:
365-011-0400-13
Regular price
$1.70
Unit price
Shipping calculated at checkout.
Description
Description
Panduit TV105-3MY | Non-Shrink Tubing
Non-Shrink PVC tubing, 3 AWG, .24" (6.32mm) inside diameter, 300 voltage rating, clear.
PVC Non-Shrink Tubing, 105C rated
Specifications
Specifications
Panduit - TV105-3MY - Product Categories
- Wire Routing, Management & Protection
- Non Shrink Tubing
Panduit - TV105-3MY - Specifications
| Brand Name | Panduit |
|---|---|
| Manufacturer Part Number | TV105-3MY |
| Item Description | Non-Shrink Tubing |
| Product Type | Non-Shrink Tubing |
| Color | Clear |
| Inside Diameter (In.) | 0.25 |
| Inside Diameter (mm) | 6.3 |
| Material | Polyvinyl Chloride |
| Maximum Operating Temperature (°C) | 105 |
| Maximum Operating Temperature (°F) | 221 |
| Maximum Voltage (V) | 300 |
| Minimum Operating Temperature (°C) | -20 |
| Minimum Operating Temperature (°F) | -4 |
| Nominal Diameter (AWG) | 3 |
| Nominal Diameter (In.) | 0.22 |
| Nominal Diameter (mm) | 5.8 |
| Overall Length (ft.) | 1000 |
| Overall Length (m) | 304.8 |
| Resistance Properties | Flame-Resistant, Heat-Resistant, Moisture-Resistant, Oil-Resistant |
| Standards Met | CSA C22.2 No. 198.1 (OFT), UL224 VW-1, MIL-I-631, RoHS Compliant |
| Wall Thickness (In.) | 0.02 |
| Wall Thickness (mm) | 0.5 |
| Application | 1) Provides Insulation and Protection for Lead Wires, Wire Harness Assemblies, Soldered Joints and Components in Electrical and Electronic Equipment, 2) All Purpose Flexible and Non-Shrinkable |
| Part Features | Provides insulation and protection for lead wires, wire harness assemblies, soldered joints and components in electrical and electronic equipment |
Panduit - TV105-3MY - Package Information
| UPC | 07498345242 |
|---|---|
| Standard Package Quantity | 1 |
| Standard Package Volume (cf) | 1.0158 |
| Standard Ctn. Quantity | 2 |
| Standard Ctn. Volume (cf) | 2.0316 |
Panduit - TV105-3MY - Videos
| Video 1 | Click to View |
|---|
Documents and Downloads
Documents and Downloads
