Brand: Panduit | SKU: 365-011-0600-13

Panduit TV105-6MY | TV105-6MY Non-Shrink Tubing

Name: Panduit TV105-6MY | TV105-6MY Non-Shrink Tubing
Brand: Panduit
SKU: 365-011-0600-13
Price: 1.47 USD
Availability: InStock

$1.47

Shipping calculated at checkout.

Description

Non-Shrink PVC tubing, 6 AWG, .17" (4.52mm) inside diameter, 300 voltage rating, clear.

PVC Non-Shrink Tubing, 105C rated
Provides insulation and protection for lead wires wire harness assemblies soldered joints and components in electrical and electronic equipment
Material: Polyvinyl chloride (PVC)
Voltage Rating: 300V and 600V
All purpose flexible non-shrinkable
Resistant to heat and moisture Applicable Specifications:
UL224 VW-1
CSA C22.2 No. 198.1 (OFT)
ASTM D-922 Grade CFR
MIL-I-631 Type F, Form U, Grade C- Class 1 Category 1

Brand Name	Panduit
Manufacturer Part Number	TV105-6MY
Item Description	TV105-6MY Non-Shrink Tubing
Product Type	Non-Shrink Tubing
Color	Clear
Inside Diameter (In.)	0.18
Inside Diameter (mm)	4.5
Material	Polyvinyl Chloride
Maximum Operating Temperature (°C)	105
Maximum Operating Temperature (°F)	221
Maximum Voltage (V)	300
Minimum Operating Temperature (°C)	-20
Minimum Operating Temperature (°F)	-4
Nominal Diameter (AWG)	6
Nominal Diameter (In.)	0.178
Nominal Diameter (mm)	4.5
Overall Length (ft.)	1000
Overall Length (m)	304.8
Resistance Properties	Oil-Resistant
Standards Met	CSA C22.2 No. 198.1 (OFT), UL224 VW-1, MIL-I-631, RoHS Compliant
Wall Thickness (In.)	0.02
Wall Thickness (mm)	0.5
Application	1) Provides Insulation and Protection for Lead Wires, Wire Harness Assemblies, Soldered Joints and Components in Electrical and Electronic Equipment, 2) All Purpose Flexible and Non-Shrinkable
Part Features	Provides insulation and protection for lead wires, wire harness assemblies, soldered joints and components in electrical and electronic equipment
