Panduit UTP28X8INRD | Patch Cord
Regular price
$21.09
Unit price
Brand: Panduit
|
SKU:
MM08IN-PA6ASD-03
Regular price
$21.09
Unit price
Description
Description
Panduit UTP28X8INRD | Patch Cord
Category 6A Performance, 28AWG, UTP Patch Cord, CM/LSZH, Red, 8in.
Cat 6A/class EA, UTP, small diameter patch cords are constructed of 28 AWG, unshielded, twisted pair, solid copper (dual-rated CM/LSZH) cable with high performance RJ45 modular plugs. patch cords are offered in multiple lengths and colors for design flexibility.
Panduit PanNet TX6A-28 Patch Cord, Class EA Small Diameter, Series: UTP28X, Category: Cat 6A, 28 AWG Conductor, F/UTP Solid Copper Conductor, RJ45 Modular Plug Connector, 8 ft Cord Length, Red, 14 to 167 deg F
Panduit - UTP28X8INRD - Features
- Quick and easy deployment in high density applications and provide efficient utilization of rack space and design flexibility
- Modified method A, pair flipped
- 100% performance tested for wire map, next and return loss
- Centered de-embedded plug
- Integral pair manager - optimizes performance and consistency by reducing untwist at plug
- Patented tangle free latch - prevents snags and provides easy release, saving time and providing reliability on frequent moves, adds and changes
- Smaller diameter, flexible cable design
- Robust construction - plug contact plated with 50 u-in of gold and rated to 2500 mating cycles
- UL 94V-0 rated clear polycarbonate housing plug
- 0.19 in OD
Specifications
Specifications
Panduit - UTP28X8INRD - Specifications
| Color | Off White |
|---|---|
| Lengths | 3 Ft. | 0.91 M |
| Connector Type | Rj45 To Rj45 |
| Shielded | U/Utp - Unshielded Twisted Pair |
| Type | Patch Cords |
| UNSPSC Code | 43223303 |
| Application | (1)10GBASE-T Ethernet(2)Data center I/O Consolidation(3) Data center server virtualization(4)Backbone aggregation(5)Parallel processing and high speed computing |
| Product Type | Patch Cord |
| Conductor Gauge (AWG) | 28 |
| Conductor Gauge (kcmil) | 0.2 |
| Performance Level | Category 6A |
| Conductor Type | Solid |
| Cable Construction | F/UTP |
| Patch Cord Type | Unshielded |
| Plug Housing Material | Polycarbonate |
| Connector 1 Type | Modular Plug |
| Connector 2 Type | Modular Plug |
| Overall Length (ft.) | 0.67 |
| Sub Brand | PanNet |
| Nominal Cable Outside Diameter (In.) | 0.19 |
| Wiring Scheme | T568B |
| Maximum Operating Temperature (°F) | 167 |
| Minimum Operating Temperature (°F) | 14 |
| Maximum Storage Temperature (°F) | 158 |
| Minimum Storage Temperature (°F) | -40 |
| Boot Color | Clear |
| UPC | 07498399435 |
