Panduit UTP6AX29OR | CBL ASSY CAT6A | CBL ASSY MOD 24-4PR SOLID UTP
The TX6A 10Gig Cat 6A UTP Patch Cord is a 29-Foot, 0.250-inch (6.4mm) diameter, Orange cord constructed of 24 AWG, unshielded, twisted pair, solid, CM cable with high-performance modular plugs. Its solid foil tape limits alien crosstalk, ensuring 10 Gb/s transmission. The tangle-free latch prevents snags and ensures a fast release, streamlining moves, adds, and changes. Enabled with RapidID, the product has pre-installed barcodes for simple port mapping using RapidID software.
Specifications
Specifications
Panduit - UTP6AX29OR - Product Categories
- Copper Systems
- Patch Cords
Panduit - UTP6AX29OR - Specifications
| Brand Name | Panduit |
|---|---|
| Manufacturer Part Number | UTP6AX29OR |
| Item Description | Pan-Net Patch Cords |
| Product Type | Patch Cords |
| Sub Brand | Pan-Net |
| Conductor Gauge (AWG) | 24 |
| Performance Level | Category 6A |
| Conductor Type | Solid |
| Cable Construction | U/UTP |
| Patch Cord Type | Unshielded |
| Plug Housing Material | Plastic |
| Jacket Material | Polyvinyl Chloride (PVC) |
| Connector 1 Type | Modular Plug |
| Connector 2 Type | Modular Plug |
| Overall Length (ft.) | 29 |
| Overall Length (m) | 8.83 |
| Nominal Cable Outside Diameter (In.) | 0.25 |
| Nominal Cable Outside Diameter (mm) | 6.4 |
| Wiring Scheme | T568B |
| Maximum Operating Temperature (°C) | 60 |
| Maximum Operating Temperature (°F) | 140 |
| Minimum Operating Temperature (°C) | -10 |
| Minimum Operating Temperature (°F) | 14 |
| Maximum Storage Temperature (°C) | 70 |
| Maximum Storage Temperature (°F) | 158 |
| Minimum Storage Temperature (°C) | -40 |
| Minimum Storage Temperature (°F) | -40 |
| Boot Color | Clear |
| Color | Orange |
| Flammability Rating | CM |
| Standards Met | Exceeds all ANSI/TIA-568.2-D Category 6A and ISO 11801 Class EA, meets ANSI/TIA-1096-A requirements (formerly FCC Part 68), meets IEC 60603-7, rated for 2500 cycles with IEEE 802.3af / 802.3at and 802.3bt type 3 and type 4, UL 1863, RoHS Compliant |
| IEC Variant | 60603-7 |
| PoE Compatibility | PoE/PoE+/PoE++ |
| Plug Type | Meets IEC 60603-371 |
| RapidID Enabled | Yes |
Panduit - UTP6AX29OR - Package Information
| UPC | 61305677310 |
|---|---|
| Standard Package Quantity | 1 |
| Standard Package Volume (cf) | 0.0744 |
| Standard Ctn. Quantity | 10 |
| Standard Ctn. Volume (cf) | 0.7435 |
