Pelco FRD1M1ST | Video Extender Receiver
Description
Description
- Manufacturer Part Number: FRD1M1ST
- Connectivity Technology: Wired
- Number of Output Devices Supported: 1
- Maximum Operating Distance: 13123.36 ft
- Serial Port: Yes
- Number of ST Ports: 1
-
Media Type Supported:
- Optical Fiber
- Coaxial
- Receiver Height: 1.10"
- Receiver Width: 5.30"
- Receiver Depth: 6.10"
-
Form Factor:
- Rack-mountable
- Standalone
- Receiver Weight (Approximate): 11.99 oz
Overview
The FTD1/FRD1 fiber transmitter and receiver provide transmission of bidirectional data over one optical fiber. The FTD1 transmitter and FRD1 receiver can be used with mult imode or single-mode optical fiber. When using single-mode fiber, the FTD1/FRD1 transmitter and receiver offer an optical budget of 23 dB and provide a transmission distance of 69 km.
The FTD1/FRD1 plug-and-play design ensures ease of installation by requiring no electrical or optical adjustments. Modular in design, FTD1 and FRD1 units can be rack-mounted using the EURACK/ USRACK chassis, or stand-alone modules can be placed on a desktop or mounted to a wall (wa ll mount kit not required).
For stand-alone and wall mount installations, external power is required for the FTD1/FRD1 units. The units can be powered with the recommended FEXTPS fiber external power supply.
Specifications
Specifications
Specifications
| Weight | 1.8 lbs |
|---|---|
| Condition | New |
| UPC | 700880297896 |
| MPN | FRD1M1ST |
| Product Type | Video Extender Receiver |
| Maximum Operating | 13123.36 ft |
| Connectivity | Wired |
| Brand | Pelco |
| Form Factor | Standalone |
