Pelco FTV40D2S1ST | Video Extender Transmitter
Description
Description
- Manufacturer Part Number: FTV40D2S1ST
- Connectivity Technology: Wired
- Number of Input Devices Supported: 4
- Maximum Operating Distance: 226377.95 ft
- Serial Port: Yes
- Number of ST Ports: 4
-
Media Type Supported:
- Optical Fiber
- Coaxial
- Transmitter Height: 2.20"
- Transmitter Width: 5.30"
- Transmitter Depth: 6.10"
-
Form Factor:
- Desktop
- Wall Mountable
- Rack-mountable
- Standalone
- Transmitter Weight (Approximate): 1.32 lb
Overview
The FTV40D2/FRV40D2 fiber transmitter and receiver transmit four channels of unidirectional video, two channels of bidirectional data, and one bidirectional contact closure over one optical fiber in a two-slot wide design. The FTV40D2 transmitter and FRV40D2 receiver are available in multimode and single-mode versions.
The FTV40D2/FRV40D2 plug-and-play design ensures ease of installation and no electrical or optical adjustments are required. Modular in design, FTV40D2 and FRV40D2 units can be rack-mounted using the EURACK/USRACK chassis, or stand-alone modules can be placed on a desktop or mounted to a wall (wall mount kit not required).
For stand-alone and wall mount installations, external power is required for the FTV40D2/FRV40D2 units. The units can be powered with the recommended FEXTPS fiber external power supply.
Specifications
Specifications
Specifications
| Weight | 1.65 lbs |
|---|---|
| Condition | New |
| UPC | 700880297780 |
| MPN | FTV40D2S1ST |
| Product Type | Video Extender Transmitter |
| Maximum Operating | 226377.95 ft |
| Connectivity | Wired |
| Brand | Pelco |
| Form Factor | Standalone |
