Brand: Pelco | SKU: 10336706

Pelco UPKT3AFSAN00A | UPKT thermal PTZ 120Vac 3x VGA 7.5Hz

Regular price $34,649.24
Shipping calculated at checkout.
  • Low prices.

    Price match guarantee

  • In-House Experts.

    We know our products

  • Easy Returns.

    Quick & Hassle Free

  • Superior Selection.

    Extensive product catalog

Description

Pelco UPKT3AFSAN00A | UPKT thermal PTZ 120Vac 3x VGA 7.5Hz

Pelco - UPKT3AFSAN00A - Features

  • PTZ unit with factory-assembled and pre-configured thermal camera and lens
  • Continuous zoom lens, 3x thermal optics, 35-105mm and digital zoom up to 8x, 24x total zoom
  • Sensor: Uncooled Microbolometer (VOx), 17Î1/4m pixel dimension
  • Analogue or IP (ONVIF S) versions
  • Advanced Autofocus system
  • Advanced Thermographic Function (STR, Spot Temperature Reading)
  • DDE, Digital Detail Enhancement
  • Dynamic adjustment of contrast (ACE, Active Contrast Enhancement)
  • Pre-wired camera and lens through snap-on connector for easy installation and maintenance
  • Total control of the auxiliary functions through the Pelco PTZ ASSISTANT (IP-based version)
  • Horizontal continuous rotation up to 100a°/sec
  • Position accuracy: 0.02a°
  • Up to 250 Presets
  • Operating temperature: -40a°C / +65a°C (-40a°F / +149a°F)
  • Power supply: 230Vac, 24Vac or 120Vac

Specifications

Pelco - UPKT3AFSAN00A - Product Categories

  • Security
  • Video Surveillance
  • Video Transmission

Pelco - UPKT3AFSAN00A - Overview

  • ULISSE RADICAL THERMAL is the first Pelco ready-to-use thermal PTZ camera system that integrates exceptional factory-assembled combinations of lens and thermal camera for unsurpassed intrusion detection and visual awareness in total darkness or extreme environmental conditions. The lens system features a continuous zoom up to 24x and an amazing AUTO FOCUS that allow quick and effective focus on targets while retaining flawless images.
  • ULISSE RADICAL THERMAL is provided with Analogue control or IP, certified ONVIF Profile S, and is compatible with most VMS on the market . The Pelco's PTZ ASSISTANT plug-in software supports any VMS with the controlof all special functions such as the Auto Focus.
  • Depending on temperature, the contrast of a scene can be adjusted dynamically by the ACE (Active Contrast Enhancement) function, while the Digital Detail Enhancement (DDE) allows more detailed and crisp images. The STR (Spot Temperature Reading) function detects the temperature reading of a specific point of the monitored scene.
  • Due to its accuracy, reliability and robustness, this thermal PTZ camera is the ideal solution for the visual control of demanding outdoor areas, such as: fire detection, military installations, border patrol, harbour surveillance, perimeter surveillance, traffic, railways and highways control and industrial monitoring.

Pelco - UPKT3AFSAN00A - Specifications

Brand NamePelco
Manufacturer Part NumberUPKT3AFSAN00A
Item DescriptionUPKT thermal PTZ 120Vac 3x VGA 7.5Hz
UNSPSC Code39121527
