Potter Electric Signal 4871190 | Nema 4x Horn Strobe, Clear Lens, Red Body, Fire With 4x Backbox
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Potter Electric Signal 4871190 | Nema 4x Horn Strobe, Clear Lens, R...
Description
Description
The Potter Weatherproof PE Series feature advanced LED technology with a range of low and high candela settings for wall and ceiling-mount applications. cutting-edge solution delivers optimal performance thanks to its NEMA type 3R and 4X ratings, which make it resistant to corrosion, ice formation. Rich in features, the devices offer 6 candela settings and 3 horn patterns within a single unit. Installation is simplified with pre-wire/pre-test capabilities via a hinged mounting plate. The PE Series is designed for 24V operations. The PE-3R/4XHN can also be used in 12V applications.
Potter Electric Signal - 4871190 - Features
- NEMA Type 3R and 4X rated for corrosion and weatherproofing
- IP54 and IP66 rated for protection against dust and water ingress
- Horn patterns (Continuous, T3, T3/T4) for fire and CO signaling in one device
- LED Technology for Energy Efficiency: Six candela settings: 15 – 185 cd, Clear: 15–185 cd, Amber: 15–177 cd
- 1/8 watt up to 8 watts (70V)
- 25 or 70 VRMS
- 6 field-selectable settings for both wall and ceiling models.
- Wall: 15 cd – 185 cd / Ceiling: 15 cd – 177 cd
- Wall or ceiling mount; 3R includes mounting plate, 4X includes backbox
- Strobe synchronization with Potter fire alarm control panels and power supplies
- Ability to mix xenon and LED strobes in the same field of view.
- 5-year warranty
Specifications
Specifications
Potter Electric Signal - 4871190 - Specifications
| Mounting Options | Ceiling or wall mount, 3R comes with mounting plate, 4X comes with backbox |
|---|---|
| Wire Gauge | #12 through #18 AWG |
| Operating Temp | 40°F to 150°F (-40°C to 66°C) |
| Maximum humidity | 0.95 |
| Dimensions | 3R: 7.8”L x 5.75”W x 1.6”H |
| Operating Voltage | 16-33 VDC/FWR. |
