Potter Electric Signal - Usa 1430502 | Fsex-Cpg-Hi: Explosion- Proof - Strobe

Potter Electric Signal - Usa - 1430502 - Additional Information

• Approved for mounting in any matter including dome up
• Synchronize with SSM module
• Current limited
• 10,000 hour strobe tube
• 3/4" NPT pendant, ceiling and wall mount options available
• Dome guard optional
• Type 4X, IP66, IPK69 enclosure
• UL Listed for Class I, Division 1, Groups C and D; Class II, Division 1, Groups E, F and G; Class I, Division 2, Groups A, B; and Class III
• Marine rated
• The Federal Signal Model FSEX-HI explosion-proof strobe light produces 80 high-intensity flashes per minute. This warning light operates on 24VDC and is unique to the market because it covers an entire range of possible mounting configurations – including dome up. This light is designed for use in alarm notification systems and is compatible with fire alarm and suppression supervised control panels and power boosters.
• The 24VDC FSEX-HI features a voltage in-rush limiting PCB design that provides greater compatibility with factory automation control systems and less electrical interference with in-rush sensitive devices.
• The Model FSEX-HI is specifically designed for explosionproof atmospheres and/or corrosive environments. Because it is easy to install and requires very low maintenance, it is ideal for use in areas such as oil rigs, mines, refineries, and chemical plants
• Specifications
• Operating Voltage - 24 VDC polarized
• Operating Current - 1.90 amps (3.0 amps in-rush)
• Flash Rate Per Minute - 80
• Candela peak - 2,000,000
• Lamp Life - 10,000 hours
• Light Source - Strobe tube
• Material - Cast Aluminum
• Operating Temperature Range - -31°F to 150°F
• Weight - Without mounting: 13.9 lbs, Ceiling mount: 4.5 lbs, Pendant mount: 2.0 lbs, Wall mount: 5.9 lbs

Potter Electric Signal - Usa - 1430502 - Product Categories

• Security
• Fire Alarm Systems
• Fire Notification

Potter Electric Signal - Usa - 1430502 - Specifications

• Potter Electric Signal - Usa 1430502 Datasheet
