Potter Electric Signal - Usa 1700002 | Pba-12010-C: 120 Vac 10" Bell - Switch

Potter Electric Signal - Usa - 1700002 - Additional Information

• These vibrating type bells are designed for use as fire, burglar or general signaling devices. They have low power consumption and high decibel ratings. The unit mounts on a standard 4" (101mm) square electrical box for indoor use or on a model BBK-1 weatherproof backbox or BBX-1 deep weatherproof backbox for outdoor applications. Weatherproof backbox model BBK-1, Stock No. 1500001.
• Specifications
• Sizes Available: 6" (150mm), 8" (200mm) and 10" (250mm)
• Voltages Available
• 24VAC
• 120VAC
• 12VDC (10.2 to 15.6) Polarized
• 24VDC (20.4 to 31.2) Polarized
• Service Use
• Fire Alarm
• General Signaling
• Burglar Alarm
• Environment
• Indoor or outdoor use (See Note 1)
• -40° to 150°F (-40° to 66°C) (Outdoor use requires weatherproof backbox.)
• Termination
• AC Bells - 4 No. 18 AWG stranded wires
• DC Bells - Terminal strip
• Finish: Red powder coating
• Optional
• Model BBK-1 weatherproof backbox
• Model BBX-1 deep weatherproof backbox
