Potter Electric Signal - Usa 4150032 | Ssx-82; 25 Watt 2-Tone Siren - Horn/Strobe

Potter Electric Signal - Usa - 4150032 - Additional Information

• Self-Contained /Indoor/Outdoor Siren and Siren/Strobe
• Sturdy aluminum back plate
• Strong polycarbonate housing
• Dual tamper protection
• Dual tone (steady and warble)
• 127dB sound output (steady and warble)
• The SSX-82 is a durable indoor/outdoor self-contained siren that is a more powerful version of the SSX-52. The full featured siren consists of a single tone that delivers a steady and warble sound output, 127dB output siren driver, and a dual action reed plunger for cover and rear protection. The SSX-82 is provided with a strong polycarbonate housing and a sturdy aluminum back plate to prevent warping and cracking. The SSX-82 comes completely assembled and ready for installation.
• The SSX-82S Siren-Strobe is also available. It includes all the great SSX-82 features with the addition of a colored strobe. The strobe uses a colored mirror and lens to ensure that the color can be easily distinguished, and is available in amber, blue, clear, or red.
• The SSX-82/82S excels in noisy areas such as warehouses, loading docks, print shops, busy production floors, or for indoor/outdoor applications where high quality and high output warning is required.
• Specifications
• Model Number: SSX-82
• Stock Number: 4150032
• Rated Voltage: 12 VDC
• Current Draw: 1.20 A Max. (typical)
• Operating Voltage Range: 4.8 - 14.4 VDC
• Speaker Specifications
• Sound Output: 127dBA
• Tamper Contact Capacity: 0.3A @ 12V DC
• Operating Temperature Range: -4™F to 149™F -20™C to 65™C
