Potter Electric Signal - Usa 4890035 | Hs24-177W Wall 177 Horn/Strobe - Enclosure

Potter Electric Signal - Usa - 4890035 - Additional Information

• Nominal Voltage 24 VDC
• Fixed177 candela strobe
• Super-Slide Bracket - ease of supervision testing
• Checkmate - Instant voltage verification
• Unit Dimensions: 5" (12.7 cm) high x 4.5" (11.43 cm) wide x 2.5" (6.35 cm) deep.
• Synchronize strobe and/or horn with AVSM Control Module
• Pre wire entire system, install mounting bracket, then install signals
• Documented lower installation and operating costs
• The HS24-177 Series is a low profile strobe, or horn/strobe combination that offers dependable audible and visual alarms with the absolute lowest current available.
• The HS24-177 Series has a minimum flash rate of 1Hz regardless of input voltage.
• The HS24-177 Series is shipped with the standard 4 mounting plate which incorporates the popular Super-Slide feature that allows the installer to easily test for supervision. The product also features a locking mechanism which secures the product to the bracket without any screws showing.
• The HS24-177 Series also features the patented Checkmate -Instant Voltage Verification feature which allows the installer to measure the voltage drop and match it to the blueprint.
• The HS-177 Series appliances are ANSI/UL 464, ANSI/UL 1971 and/or ANSI/UL 1638 listed for use with fire protective systems and are warranted for five years from date of purchase.

Potter Electric Signal - Usa - 4890035 - Product Categories

• Security
• Fire Alarm Systems
• Fire Alarm Accessories

Potter Electric Signal - Usa - 4890035 - Specifications

• Potter Electric Signal - Usa 4890035 Datasheet
