Potter Electric Signal - Usa 4890062 | Hs-24Pwr-Wp Horn/Strobe Plain - Horn/Strobe

Potter Electric Signal - Usa - 4890062 - Additional Information

• 24VDC units have field selectable candela options of 15, 30, 60, 75, & 110
• Super-Slide Bracket Ease of Supervision Testing
• Checkmate Instant Voltage Verification
• Synchronize strobe and/or horn with AVSM Control Module
• Prewire entire system, install mounting bracket, then install signals
• Documented lower installation and operating costs
• Input terminals accept 12 to 18 AWG
• Switch selection for high or low dBA
• The HS-24 Series is a low profile strobe and horn/strobe combination that offers dependable audible and visual alarms and the absolute lowest current available.
• The HS-24 Series 24VDC offers tamperproof field selectable candela options of 15, 30, 60, 75, and 110 candela.
• The Strobe and Horn/Strobe offers a continuous or sync temporal three in 2400Hz and mechanical tone, a chime and whoop tone. All tones are easy for the professional to change in the field by the use of switches.
• The HS-24 Series has a minimal operating current and has a minimum flash rate of 1Hz regardless of input voltage.
• This Series is shipped with a standard 4" metal mounting plate which incorporates the popular Super-Slide feature that allows the installer to easily test for supervision. The product also features a locking mechanism which secures the product to the bracket without any screws showing.
• The HS-24 also features the patented Checkmate - Instant Voltage Verification feature which allows the installer to check the voltage drop draw and match it to the blueprint.
• The HS-24 Series appliances are ANSI/UL 464 and ANSI/UL 1971, listed for use with fire protective systems and are warranted for three years from date of purchase.

Potter Electric Signal - Usa - 4890062 - Product Categories

• Hardware and Supplies
• Tools and Supplies
• Miscellaneous

Potter Electric Signal - Usa - 4890062 - Specifications

• Potter Electric Signal - Usa 4890062 Datasheet
