Potter Electric Signal - Usa 4890071 | Lfh-24W Low Freq Sounder - Horn

Potter Electric Signal - Usa - 4890071 - Additional Information

• Super-Slide Bracket Ease of Supervision Testing
• Wall or Ceiling mount
• Checkmate Instant Voltage Verification
• Synchronize horn with Potter GTSM module
• Produces a 520Hz square wave, temporal 3 tone
• Jumper selection for normal or loud dBA
• Temporal 4 pattern available when used with GTSM module
• Tamperproof re-entrant style grill and locking screw (Optional)
• The LFH horn offers a 520Hz square wave, temporal 3 tone. A jumper selection is available for normal or loud decibel tone. A temporal 4 pattern is available when used with the Potter GTSM Synchronization Control Module.
• The LFH is equipped with a universal 4 metal mounting bracket which incorporates the popular Super-Slide feature that allows the installer to easily pre-wire the system and test for supervision. The product also features a locking mechanism that secures the signal to the bracket without showing any screws and the Checkmate - Instant Voltage Verification Feature which allows the installer to check thevoltage drop, current draw, and match against the blue print.
• Specifications
• Operating Voltage: Nominal 24VDC (16-33VDC)
• Operating Temperature: 32°F - 120°F (0° - 49°C)
• Dimensions: 6-1/8 H x 5 1/2 W x 1-5/8 D
• Wiring Connections: Terminals accept 18 - 12 AWG
• Mounting: Single gang, double gang, or 4 square back box
