Potter Electric Signal - Usa EVX-SL8 | 8 Programmable Switch Led Card - Fire Evac

Potter Electric Signal - Usa - EVX-SL8 - Additional Information

• 4 Class B or 2 Class A Field Selectable Speaker Circuits
• 25/70 Vrms Field Selectable
• Configurable with EVX-SL8 for Zone Selection
• Smart Power detection, provides short circuit protection
• Up to 64 circuits on a system
• Up to 50W on any circuit at 70V
• The EVAX EVX-SL8 LED Switch Module provides switch selection for message activation, paging, and control functions. When used in conjunction with the EVX-ZM zone module, the SL8 can be programmed for page zone control. LEDs for switches assigned to page zones will indicate Red for page and flashing Red for alarm. The LED will indicate Amber if the associated speaker circuit is in a fault condition. Switches can be programmed to control corresponding points on the EVX-OL8. Switch LEDs will indicate steady Red on activation.
• Specifications
• Standby Current - 3.0mA
• Active Current - 3.23mA
• All Call Current - 5.16mA

Potter Electric Signal - Usa - EVX-SL8 - Product Categories

• Security
• Fire Alarm Systems
• Control Panels

Potter Electric Signal - Usa - EVX-SL8 - Specifications
