Powersonic 1202608402 | PS-12260B 12V 26Ah Battery (B Terminals)
Description
Description
The PS-12260 is part of our General Purpose SLA range. This 12.0V and 26.0Ah battery provides dependable power for general purpose and standby uses. Features include AGM Technology, Gas Recombination, Power Volume Ratio, SLA ABS Case, and SLA Maintenance Free. These batteries are commonly used in Emergency Lighting, Fire Security, General Purpose, Medical, Signaling (Air,Rail,Sea), Solar, Telecomm, UPS, Utility, and Wind requiring reliable, light cyclic backup power. Backed by decades of expertise, Power-Sonic batteries are subject to stringent quality controls through each step of the manufacturing process to ensure compliance, performance consistency, and reliability.
Specifications
Specifications
Powersonic - 1202608402 - Specifications
| Nominal Voltage | 12.0 Volts, (6.0 cells) |
|---|---|
| Stored Energy (Wh) | 312.0 |
| Cycle Constant Voltage Range | 14.10V-14.40V-30mV/? |
| Float Constant Voltage Range | 13.50V-13.80V-18mV/? |
| Initial Charging Current (A) | 7.8 |
| Max Continuous Discharge Current (A) | 260.0 |
| Internal Resistance (m?) | 13.0 |
| Short Circuit Current (A) | 650.0 |
| Recommended Chargers | PSC-122000ACX |
| Case Material | ABS (UL94 HB or V-0 optional) |
| Approximate Weight lbs (kg) | 16.76 (7.6) |
| VDS Weight lbs (kg) | 17.6 (8) |
| Width in (mm) | 6.93 (176.0) |
| Height in (mm) | 4.92 (125.0) |
| Height Over Terminal in (mm) | 4.92 (125.0) |
Documents and Downloads
Documents and Downloads
