Prysmian Group 7151851 | 23 AWG 4-Pair Category 6A UTP Plenum (CMP) Cable, Gray
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Prysmian Group 7151851 | 23 AWG 4-Pair Category 6A UTP Plenum (CMP)...
Description
Description
Genspeed 10MTP is the world’s first category 6A cable to feature a recordbreaking 0.230” overall diameter with guaranteed performance that meets or exceeds all TIA standards, providing industry- leading alien crosstalk protection and EMI immunity. Without needing to be grounded, genspeed 10 mtp’s mosaic variable laser cut tape shields the cable from noise coming from external cable sources (PSANEXT and PSAACRF). Its improved design, reduced diameter, lighter weight and increased flexibility translates to simplified cable handling and optimized cable management: less conduit, less cable tray and more cable in existing conduit and trays which lowers overall project costs.
Prysmian Group - 7151851 - Features
- Mosaic™ variable laser cut tape provides enhanced alien cross-talk protection: guaranteed +8 dB over TIA 568.2-D for both PSANEXT & PSAACRF
- Best EMI immunity in UTP cable utilizing Mosaic™ Variable Laser Cut Tape
- Record-breaking outside diameter of 0.230 inch for plenum supports higher cable density and easier pathway fill.
- Small 0.250-inch nominal cable diameter for Riser supports easier pathway fill for conduits.
- The smaller diameter design simplifies installation by allowing a 1?inch bend radius and reducing overall cable weight to increase the speed of stripping, termination, and routing.
- Improved distribution and warehousing efficiency UL Listed CMP?LP 0.7A (or 140W) for high power PoE applications.
- UL Listed CMP?LP 0.5A, or 100W, for high-power PoE applications.
- 105°C CMP jacket rating supports higher operating temperatures and high?wattage applications in a wide range of operating environments, allowing a simplification of system designs for today’s PoE systems.
- Can contribute toward LEED Points
- Weighs just 30 pounds (>20% less than competition)
- TRU?Mark® footage markings from 1000' to 0' streamline pulls and inventory control.
- Made in the U.S.A. for consistent quality and supply assurance.
- >Feature Title< = Prysmian Group - 7151851 - Product Categories
- https://cdn.shopify.com/s/files/1/0843/1616/0235/files/product_classification.jpg?v=1786475215
- IEEE 802.3 10GBASE?T, 1000BASE?T, 100BASE?TX, 10BASE?T.
- PoE, PoE+, and PoE++ high?power applications.
- ANSI/TIA 854 1000BASE?TX networks.
- Digital video distribution.
- Broadband and baseband analog video.
- CDDI, Token Ring, and ATM backbone or horizontal links.
- ANSI/TIA-1179-A Healthcare facilities.
Specifications
Specifications
Prysmian Group - 7151851 - Product Categories
- Network Cabling Infrastructure
- Copper Cabling Infrastructure
- Copper Data Cable
- Cat 6A Cable
Prysmian Group - 7151851 - Product Categories
- Network Cabling Infrastructure
- Copper Cabling Infrastructure
- Copper Data Cable
- Cat 6A Cable
Prysmian Group - 7151851 - Specifications
| Manufacturer Name | Prysmian Group |
|---|---|
| Manufacturer Part Number | 7151851 |
| Item Description | 23 AWG 4-Pair Category 6A UTP Plenum (CMP) Cable, Gray |
| Bend Radius | 1 In. |
| Category/Level | Category 6A |
| Conductor/Pair Count | 4 Pair |
| Cable Diameter | 0.23 In. |
| Cable Weight | 30 Lb./1000 Ft. |
| Conductor Size | 23 Awg |
| Conductor Type | Solid |
| Country Of Origin | U.S.A. |
| Fire Rating | Plenum |
| Gauge | 23 Awg (American Wire Gauge) |
| Jacket Color | Gray |
| Length | 1000 Ft. |
| Operating Temperature | -20 To +105 Degrees Celsius |
| Pair Count | 4 Pair |
| Product Type | Category 6A Cable |
| Pulling Force | 40 Lb. |
| Shielded | U/Utp - Unshielded Twisted Pair |
| Shielded | U/Utp - Unshielded Twisted Pair |
| Special Rating | Ul 444; Ul 4299 |
| Type | Data |
