Brand: RFS Technologies Inc | SKU: 9823157

RFS Technologies Inc LCF12-50J-P7 | Foam Dielectric Coaxial Cable, 50 Ohm

Name: RFS Technologies Inc LCF12-50J-P7 | Foam Dielectric Coaxial Cable, 50 Ohm
Brand: Anixter
SKU: 9823157
Availability: InStock

$0.00

Shipping calculated at checkout.

Description

Manufacturer Part Number	LCF12-50J-P7
Manufacturer	RFS Technologies Inc
BRAID %	NO BRAID
Bend Radius	5 in.
COAX CONSTRUCTION	COAXIAL
COAX TYPE	HELIAX
Cable Type	Foam-Dielectric
Capacitance	76 pF/m
Conductor Material	Copper-Clad Aluminum/Corrugated Copper
Conductor Size	0.19 x 0.54 in.
Conductor Type	Solid
DIELECTRIC MATERIAL	PE-POLYETHYLENE (SOLID)
FLOODED	NO NOT FLOODED OVER BRAID
Frequency Rating	8.8GHz
IMPEDANCE	50 OHM NOMINAL IMPEDANCE
Impedance	50 ?
JACKETING MATERIAL	PE-POLYETHYLENE
Jacketing Material	Polyethylene
MATERIAL	COPPER CLAD ALUMINUM
Nominal Size	1/2 in.
OUTDOOR	YES IS OUTDOOR GRADE MATERIAL
Outside Diameter	0.62 in.
Power Rating	38 kW
Product Type	Coaxial Cable
Resistance	1.5 ?/Km, 2.7 ?/Km
SPEC/STND NEC	NOT LISTED BY UL UNDER NEC
Shield Type	Corrugated
Temperature Rating	-58 to +185 F
Voltage	1950 V
