Description
Description
Seco-Larm SD-6276-SSVQ | Piezoelectric Request-to-Exit Pushbutton - Single-gang with Manual Override
Seco-Larm - SD-6276-SSVQ - Features
- ETL, Conforms to UL Std. 294
- LED ring around button changes from green to red or red to green when the button is pressed
- Timed or toggle output
- Manual override button in case power to piezoelectric pushbutton fails
- SPDT Relay rated 2.5A@24 VAC/VDC with two individually programmable outputs (NO/NC)
Specifications
Specifications
Seco-Larm - SD-6276-SSVQ - Specifications
| Brand Name | Seco-Larm |
|---|---|
| Manufacturer Part Number | SD-6276-SSVQ |
| Item Description | Piezoelectric Request-to-Exit Pushbutton - Single-gang with Manual Override |
| Operating voltage | 12~24 VDC |
| Current drain | 40mA@12VDC |
| Contact rating | 2.5A@24 VAC/VDC |
| Standby: Red | Active:Green |
| Output time | 1~30 s, Toggle |
| Destructive attack level | Level I |
| Line security | Level I |
| Endurance level | Level I |
| Standby power | Level I |
| Operating temperature | 32º~158º F (0º~70º C) |
| Plate Material | Stainless steel |
| Weight | 4-oz (113g) |
| Category | Access |
