Brand: Seco-Larm Usa | SKU: 10606412

Seco-Larm Usa SK-910RD1-W | RF Receiver, 1-Channel, 26-Bit Wiegand Output/Input

$60.05

Shipping calculated at checkout.

Low prices.

Price match guarantee
In-House Experts.

We know our products
Easy Returns.

Quick & Hassle Free
Superior Selection.

Extensive product catalog

Description

Seco-Larm Usa SK-910RD1-W | RF Receiver, 1-Channel, 26-Bit Wiegand Output/Input

The ENFORCER RF Receiver with Wiegand captures wireless RF signals from compatible transmitters and converts them into standard Wiegand output. It transmits the converted data directly to access control panels. Supporting 26-bit Wiegand formats, it ensures seamless integration with ENFORCER and third-party controllers.

Seco-Larm Usa - SK-910RD1-W - Features

Operates as Wiegand 26-bit reader, controller, or stand-alone
1-Channel (1 Form C relay output)
Can learn up to 240 codes from RF transmitters or Wiegand keypads/readers
Compatible with an optional card reader featuring Wiegand output
Dual frequency support (315/433.92MHz)

Specifications

Seco-Larm Usa - SK-910RD1-W - Specifications

Operating frequency	315MHz
Memory capacity	240
Operating voltage	10~24 VAC/VDC
Relay output modes	0.5~99 sec momentary (default, 1s), 1~99 min momentary, toggle, latch, follow (validity)
Wiegand	26-bit, selectable input or output (default – output)
Connectors	Screw terminals, +, -, with NO/NC/COM per relay, Wiegand GND/WGD0/WGD1
Digital display	2-digit, 7-segment LED
Operating humidity	5~95%, non-condensing
Operating temperature	-40°~167° F (-40°~75° C)
Dimensions	4-3/16?x7/8?x2-3/8? (107x23x60 mm)
