Security Door Controls 1582XD | 650lb Holding Force EMLocks
Description
Description
SDC's electromagnetic locks are suited for interior doors, perimeter exit doors and entrances that require failsafe emergency release capability. The patented EMLock® design represents the pinnacle of magnetic lock evolution with modular assembly that makes them easy to stock, install, upgrade and maintain. The housing design provides a superior appearance with a plated or anodized finish on all sides. The interlocking EZ mount assembly leaves hands free for wiring and securing of mounting screws. EMLocks® are UL listed and ANSI grade 1 compliant
Security Door Controls - 1582XD - Features
- Uniform design and installation
- Wire access chamber with terminal block
- Interlocking quick mount assembly
- Auto-sensing dual voltage
- Voltage and current spike protection
- Instant release anti-residual magnetism circuitry
- Captive lock mounting screws
- Self-drilling and tapping sheet metal screws
- 10/32” machine screws included
Specifications
Specifications
Security Door Controls - 1582XD - Specifications
| Housing | Aluminum |
|---|---|
| Door Type | Swing, Double |
| Holding Force | 650 lbs |
| Dimensions | 171/2” x 21/8” x 11/4” Housing, 63/8” x 11/2” x 1/2” Armature |
| Weight | 8 lbs |
| Input | 12/24 VDC ± 10% Auto-sensing |
| Product Type | Double Electromagnetic Lock |
| Input Voltage | Selectable 12 Or 24 Volt Dc |
| Sales Category | Electric Magnetic Lock |
| Switches | Bond Sensor And Door Status |
| Ul Listing | Ul Listed |
| UNSPSC Code | 46171500 |
