Servertech C4G36RAGNBD2FE1 | Switched POPS PDU - 11.5kW
Description
Description
Server Technology's PRO4X Switched POPS PDUs run on our state-of-the-art Xerus network interface platform and provide remote access to power, PDU status, input, outlet and branch current monitoring, and outlet on/off control. The PDU features RamLock, a self-locking mechanism to prevent accidental cord disconnects, and our award-winning HDOT Cx outlets that can be deployed as either a C13 or C19. Switched POPS PDUs are secured with strong configurable password, active directory, 256-bit AES encryption, SSH, SSL and HTTPS support. SNMP traps provide automated alerts on power and environmental conditions from Legrand's plug-and-play environmental monitoring sensors like temperature, humidity, water, dry contact closure, airflow, air pressure differential, and more.
Servertech - C4G36RAGNBD2FE1 - Features
- HDOT Cx Outlets
- Multi-Unit Linking & Cascading
- Power Quality Measurements
- RamLock Locking Outlets
- Branch Circuit Protection
- Alternating-Phase Outlets
- Environmental Monitoring
- RGB LED Outlet Indicators
Specifications
Specifications
Servertech - C4G36RAGNBD2FE1 - Specifications
| Input Voltage (V) | 415 |
|---|---|
| Input Plug | 230/400 16A & 240/415V Wye 20A IEC 60309 3P+N+G 6Hr |
| Input Current (A) | 20 |
| Input Power Capacity (kW) | 11.5 |
| 12) x IEC 60320/C13 | North American Rating: ? 12A @208V L-N (15A Peak) |
| Operating Environment | 32°F to 140°F / 0°C to 60°C |
| Dimensions | 70.0in tall x 2.2in wide x 2.5in deep [1778mm x 56mm x 64mm] |
