Servertech C4S36RAEPBE2FE2 | SmartPro4X IX PDU, 36RA MLCK HDOT, (12) C13 + (24) Cx, 0309 1P+N+G, 6hr Blue Plug, 3m (9.84ft)
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Servertech C4S36RAEPBE2FE2 | SmartPro4X IX PDU, 36RA MLCK HDOT, (12...
Description
Description
Server Technology's PRO4X Smart PDUs run on our state-of-the-art Xerus network interface platform and provide remote access to power, PDU status, input and branch current monitoring. The PDU features RamLock, a self-locking mechanism to prevent accidental cord disconnects, and our award-winning HDOT Cx outlets that can be deployed as either a C13 or C19. Smart PDUs are secured with strong configurable password, active directory, 256-bit AES encryption, SSH, SSL and HTTPS support. SNMP traps provide automated alerts on power and environmental conditions from Legrand's plug-and-play environmental monitoring sensors like temperature, humidity, water, dry contact closure, airflow, air pressure differential, and more.
Servertech - C4S36RAEPBE2FE2 - Features
- Cx is the future-ready UL tested hybrid of a C13 and C19 outlet accommodating both C14 and C20 plugs
- Daisy chain up to 16 PDUs from a primary PDU using a USB or Ethernet connection through a single IP address
- Monitor and alert on the power being fed to the PDU for harmonics, voltage dips and swells, crest factor, and more at the outlet or load
- Support up to 12 daisy chained DX2-series SmartSensors, each with the ability to send SNMP-based alerts and email notifications
- Evenly distributes multiple phases of power to each outlet for simplified load balancing, reduced cord lengths, and better airflow
- An easy-to-read LCD provides a local indication of power usage, alerts, and alarms
- RGB LEDs identify an outlet's on/off state, if it's above/below a certain power threshold, or if it's in suspect of a power measurement irregularity
- PIPS® (Per Inlet Power Sensing) Monitors Current Load (A), Voltage (V), Power (W), Apparent Power (VA), Crest Factor, Power Factor, & Energy per inlet
- The Controller is the PDU's center of intelligence and houses computing, display, and connectivity ports
- Gain access to valuable data through connections including HTTP(S), SSH, Telnet, SNMP, (S)FTP, SMTP, Syslog, LDAP(S), RS-232 serial, and more
Specifications
Specifications
Servertech - C4S36RAEPBE2FE2 - Specifications
| Input Voltage (V): | 230 |
|---|---|
| Input Plug: | IEC 230V/32A 2P+PE 6Hr |
| Input Current (A): | 32 |
| Input Current Rated (A): | 32 |
| Input Power Capacity (kW): | 7.3 |
